GB/UK
ELECTRIC STOVE
Series 650
Models:
FOE/30 , FOE/31 , FOE/32L , FOE/32C
Installation and Operation Manual
105321
105343
105322
105323
Revò.: 1 / 3.2011
S/N:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 650 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Bartscher 650 Series

  • Page 1 GB/UK ELECTRIC STOVE Series 650 Models: FOE/30 , FOE/31 , FOE/32L , FOE/32C Installation and Operation Manual 105321 105343 105322 105323 Revò.: 1 / 3.2011 S/N:...
  • Page 3: Table Of Contents

    *.3.2011 Rev. 1.0 1.General ............................1 1.1 Symbols used in the manual ....................1 1.2 Symbols affixed to the appliance ................... 1 1.3 Checking correspondence between the handbook and the appliance ....... 2 2. Safety ............................. 3 2.1 Using the appliance safely ...................... 3 2.2 Safety instructions in case of malfunction ................
  • Page 4 *.3.2011 Rev. 1.0 5. Installation ..........................10 5.1 General information ......................10 5.2 Storage ........................... 10 5.3 Unpacking the appliance ...................... 10 5.4 Disposing of packaging materials ..................11 5.5 Installation ..........................11 5.6 Electrical connection ......................12 5.6.1 Connecting the connection cable to the terminal block (countertop and freestan dingranges) ........................
  • Page 5: General

    *.3.2011 Rev. 1.0 General 1. General Read the instructions in this handbook carefully: they contain important information regarding proper, efficient and safe installation, operation and maintenance of the appliance. Keep this handbook in a safe place where it is readily available for consultation by other users of the appliance.
  • Page 6: Checking Correspondence Between The Handbook And The Appliance

    *.3.2011 Rev. 1.0 General 1.3 Checking correspondence between the handbook and the appliance The appliance serial number is shown on the rating plate. If the handbooks are misplaced, new copies may be ordered from the manufacturer or the local dealer. When ordering new handbooks always quote the serial number shown on the rating plate.
  • Page 7: Safety

    *.3.2011 Rev. 1.0 Safety 2. Safety 2.1 Using the appliance safely TBeing designed for professional use, this appliance should be used by qualified person nel only. Never leave the appliance unattended while in use! Do not move the appliance while hot! IF OIL SHOULD CATCH FIRE, NEVER USE WATER TO EXTINGUISH IT.
  • Page 8: Functional Description

    *.3.2011 Rev. 1.0 Functional description 3. Descrizione funzionale 3.1 Intended use This electric range is intended to cook food in pots and pans placed on the cooking plates. 3.1.1 Prohibited use This electric range is not designed to cook food directly on the cooking plates. 3.2 Construction Stainless steel bearing structure resting on four height-adjustable feet.
  • Page 9: Operating Principle

    *.3.2011 Rev. 1.0 Functional description 3.3 Operating principle The heating elements underneath the cooking plates heat their surface to the desired temperatu When cooking food, any energy savings will depend on the quality of pots and pans, and in particular of their bottom. Pots and pans should have a diameter slightly larger than the cooking plate and be suitable for electric cooking plate cooking.
  • Page 10: Operating Instructions

    *.3.2011 Rev. 1.0 Operating instructions 4. Operating instructions 4.1 Before using the appliance 4.1.1 Preparing the use Remove all packaging materials and adhesive films from the range very carefully. Remove the protective plastic film from the panels, being careful not to leave any traces of glue on the steel surface;...
  • Page 11: Using The Appliance

    *.3.2011 Rev. 1.0 Operating instructions 4.2 Using the appliance 4.2.1 Turning on the appliance Turn appliance using safety switch located outside appliance. By turning the knob to the desired effect setting, the pilot light will go on and the cooking plate will start heating.
  • Page 12: After-Use Care

    *.3.2011 Rev. 1.0 Operating instructions 4.3 After-use care 4.3.1 Cleaning Before carrying out any cleaning or maintenance operations, turn the appliance off and disconnect it from the electricity supply. The main causes for stainless steel wear or corrosion are: • using abrasive or acid detergents, especially chlorine-based products such as hydrochloric acid or sodium hypochlorite (bleach).
  • Page 13: Idle Period

    *.3.2011 Rev. 1.0 Operating instructions Scratches and dark stains Scratches and dark stains may be smoothed or removed by using stainless steel wool pads or synthetic abrasive sponges, rubbing always in the same direction as the satin finish. Rust If you need to remove rust stains, contact manufacturers of industrial detergents to find a suitable product.
  • Page 14: Installation

    *.3.2011 Rev. 1.0 Installation 5. Installation 5.1 General information The manufacturer cannot be held liable for any damage to property or injury to persons due to installation errors or inappropriate use of the appliance. Check that the appliance is preset to use the voltage rating available at the location where it is installed.
  • Page 15: Installation

    *.3.2011 Rev. 1.0 Installation 5.5 Installation If the range is installed near other electrical appliances, ensure that they do not interfere with each other. Each applience should have an independently used power supply. Before turning on any heating element, make sure that all packaging materials and protective films have been removed.
  • Page 16: Electrical Connection

    *.3.2011 Rev. 1.0 Installation 5.6 Electrical connection Connecting a Y-type power cord. Follow the installation instructions and the information on the rating plate when connecting the unit. Comply with all local regulations and standards! Each appliance requires an independent fused power supply line. On-site installation: provide accessible all-pole disconnection device with a minimum of a 3 mm contact gap.
  • Page 17: Air Conditioning

    *.3.2011 Rev. 1.0 Installation 5.7 Air conditioning The appliance should be installed in a well-ventilated area, if possible under a hood, in compliance with applicable regulations in force. 5.8 Staff training Instruct the personnel in the use of this appliance by referring to the user’s manual and hand out the manual to them.
  • Page 18: Troubleshooting

    *.3.2011 Rev. 1.0 Troubleshooting 6. Troubleshooting If the appliance fails to work, check the fuse box for blown fuses (overload protection). Have the overload protection device checked by a qualified technician. Users are not allowed to perform any maintenance operations on any parts of this appliance. Maintenance should be carried out by an authorized technician.
  • Page 19: Spare Parts

    *.3.2011 Rev. 1.0 Spare parts 7. Spare parts 7.1 Product codes Serie 650 Product code Full name 1008310 FOE30 1008300 FOE31 1008330 1/N/PE FOE32L 1008335 3/N/PE 1008320 1/N/PE FOE32C 1008325 3/N/PE...
  • Page 20: Technical Specifications

    *.3.2011 Rev. 1.0 Technical specifications 8. Technical specifications Connection diagrams ......20 Installation and connection drawings..24 Technical specifications table ....29...
  • Page 21 *.3.2011 Rev. 1.0 Technical specifications 6LE00267 FOE30 1/N/PE~230V 50-60Hz Codice Sigla Descrizione Caratteristiche elettriche 6A038506 Lampada di funzionamento piastra 400V - 150 C 6A045301 Elemento riscaldante 2000W - 230V MA1616100 Commutatore 7 POS.
  • Page 22 *.3.2011 Rev. 1.0 Technical specifications 6LE00270 FOE31 3/PE~400V 50-60Hz Codice Sigla Descrizione Caratteristiche elettriche 6A038506 Lampada di funzionamento piastra 400V - 150 C 6A036500 Elemento riscaldante 3500W 400V D.300mm MA1937800 Commutatore 7 POS.
  • Page 23 *.3.2011 Rev. 1.0 Technical specifications 6LE00268 FOE32L-C 3/PE~400V 50-60Hz Codice Sigla Descrizione Caratteristiche elettriche 6A038506 HL1-2 Lampada di funzionamento piastra 400V - 150 C 6A045600 Elemento riscaldante 2600W - 400V D. 220mm 6A048910 Elemento riscaldante 2000W - 400V D. 180mm MA1616100 SA1-2 Commutatore...
  • Page 24 *.3.2011 Rev. 1.0 Technical specifications Installation and connection drawings FOE/31 41.3 cm 41.3 cm 50 cm 30 cm 25 cm 25 cm 50 cm DESCRIPTION Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 25 *.3.2011 Rev. 1.0 Technical specifications Installation and connection drawings FOE/32L 56 cm 31 cm 35 cm 22 cm 17 cm 26 cm 17 cm 60 cm 18 cm DESCRIPTION Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 26 *.3.2011 Rev. 1.0 Technical specifications Installation and connection drawings FOE/32C 56 cm 31 cm 35 cm 22 cm 18 cm 17.5 cm 17.5 cm 35 cm DESCRIPTION Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 27 *.3.2011 Rev. 1.0 Technical specifications Articolo Specifiche Modello FOE 30 N° e power plate 1 x 2 kw N° e power plate FOE 31 (400V) 1 x 3,5 kw N° e power plate FOE 32/L FOE 32/C (230V) 1 x 2 kw / 1 x 2,6 kw FOE 32/L FOE 32/C (400V) N°...
