Summary of Contents for SICK MAX48

  • Page 1 B E T R I E B S A N L E I T U N G MAX48...
  • Page 2 B E T R I E B S A N L E I T U N G MAX48...
  • Page 3: Zu Ihrer Sicherheit

    Leitungen nicht über scharfe Kanten oder heiße Oberflächen legen. Ausreichende Biegeradien und Zugentlastungen verwenden. 8021471/2017-08-01 | SICK B E T R I E B S A N L E I T U N G | MAX48 Irrtümer und Änderungen vorbehalten...
  • Page 4: Elektrische Installation

    Abbildung 2: Pinbelegung M12 Pinbelegung gemäß Typenschlüssel, Position 13. Pinbelegung M12 Typenschlüssel 12/24 VDC GND (0 V) B E T R I E B S A N L E I T U N G | MAX48 8021471/2017-08-01 | SICK Irrtümer und Änderungen vorbehalten...
  • Page 5 Einfluss auf die Schirmung und die Signale im Kabel haben. 8021471/2017-08-01 | SICK B E T R I E B S A N L E I T U N G | MAX48 Irrtümer und Änderungen vorbehalten...
  • Page 6 Während der Einschaltzeit ist der Signalausgang am Gerät ≥ F.S.O = Full Scale Output. Danach ist das Gerät betriebsbereit. B E T R I E B S A N L E I T U N G | MAX48 8021471/2017-08-01 | SICK...
  • Page 7 Abweichungen von den Soll-Werten. Die Abweichungen sind bei der Festlegung von Grenzwerten in der auslesenden Steuerung zu berücksichtigen: 8021471/2017-08-01 | SICK B E T R I E B S A N L E I T U N G | MAX48 Irrtümer und Änderungen vorbehalten...
  • Page 8 Abfallbeseitigungsvorschriften zu entsorgen. Als Elektronikschrott darf das Gerät keinesfalls dem Hausmüll beigegeben werden. B E T R I E B S A N L E I T U N G | MAX48 8021471/2017-08-01 | SICK Irrtümer und Änderungen vorbehalten...
  • Page 9 O P E R A T I N G I N S T R U C T I O N S MAX48...
  • Page 10: Safety Information

    Do not lay any cables across sharp edges or hot surfaces. Use adequate bend radii and strain-relief clamps. O P E R A T I N G I N S T R U C T I O N S | MAX48 8021471/2017-08-01 | SICK...
  • Page 11: Electrical Installation

    M12 pin assignment Type code 12/24 VDC GND (0 V) 8021471/2017-08-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MAX48 Subject to change without notice...
  • Page 12: Connection Sequence

    Any high voltage or high frequency fields in the vicinity can influence the shielding and the signal in the cable. O P E R A T I N G I N S T R U C T I O N S | MAX48 8021471/2017-08-01 | SICK...
  • Page 13: Commissioning The Device

    When switching on the device, the signal output is ≥ F.S.O = Full Scale Output. After that the device is ready for use. 8021471/2017-08-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MAX48 Subject to change without notice...
  • Page 14 These deviations must be taken into consid‐ eration when setting limit values in the controller: O P E R A T I N G I N S T R U C T I O N S | MAX48 8021471/2017-08-01 | SICK...
  • Page 15: Maintenance

    As the device is categorized as electronic waste, it must never be disposed of with household waste. 8021471/2017-08-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MAX48 Subject to change without notice...
  • Page 16 Phone +36 1 371 2680 Phone +386 591 788 49 E-Mail office@sick.hu E-Mail office@sick.si India South Africa Phone +91 22 6119 8900 Phone +27 11 472 3733 Further locations at www.sick.com E-Mail info@sick-india.com E-Mail info@sickautomation.co.za SICK AG | Waldkirch | Germany | www.sick.com...
