  • Page 1 O P E R A T I N G I N S T R U C T I O N S MPS-C Magnetic position sensor...
  • Page 2 This document is an original document of SICK AG. 2006/42/EC SAFETY O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    General notes on operation..............Teach-in mode................... Maintenance..................33 Maintenance..................... Repairs...................... 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 4 11.4 Ambient data..................... Annex....................37 12.1 Conformities and certificates..............O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 5: About This Document

    ✓ The tick denotes the results of an action. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 6: Safety Information

    O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...

  • Page 7: Requirements For Skilled Persons And Operating Personnel

    SICK AG. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 8: Product Description

    The MPS-C determines the position of an encoder magnet via a row of Hall sensors. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...
  • Page 9 The linearity error describes the maximum deviation of the output signal from an ideal straight line. It is measured in millimeters. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 10: Transport And Storage

    For storage periods of longer than 3 months, check the general condition of all ■ components and packaging on a regular basis. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 11: Mounting

    If the setscrews on the sensor housing are tightened excessively, the sensor may be damaged. Observe the maximum tightening torque of 0.4 Nm. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 12 Push the sensor into the C-slot and tighten both setscrews between 0.2 Nm and 0.4 Nm2. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...

  • Page 13: Electrical Installation

    8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 14 Prevent equipotential bonding currents via the cable shield with a suitable grounding method, see "Safety", page O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 15: Pin Allocation Of The Connections

    DIN VDE 0298 (part 4) and/or DIN VDE 0891 (part 1) 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 16: Wiring The Digital Switching Output

    ≤ 2 V at I = 100 mA Figure 8: Wiring the switching output O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 17: Commissioning

    To configure the sensor, either the capacitive keypad (see "Operation", page 18) or IO-Link is used. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 18: Operation

    The behavior of the LEDs in teach-in mode differs from the table below. See the information in the individual sections relating to the teach-in steps. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...

  • Page 19: General Notes On Operation

    SP1 - hysteresis > 0 • SP2 - hysteresis > 0 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 20 The hysteresis is above and below this range. NOTE Additional condition: hysteresis < |SP1 - SP2| O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...
  • Page 21 Switching point SP1 Switching point SP2 Working range Hyst. Hysteresis 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 22: Teach-In Mode

    A timeout is also triggered if a teach-in process has been started and no activity is registered at the keypad for 30 seconds after this. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...
  • Page 23 4 Hz 4 Hz = lights up, = flashes, = off 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 24 No magnet detected when teaching in the start or end of the measuring range. • Value below minimum measuring range (> 1 mm). O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...
  • Page 25 Lift your finger. ✓ The measuring range is reset. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 26 ✓ The operation LED lights up permanently in the color of the selected output. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...
  • Page 27 Lift your finger. ✓ The analog output supplies inverted current/voltage values. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 28 Lift your finger. ✓ The switching point is defined. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...
  • Page 29 Lift your finger. ✓ The fixed switching range is defined. 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 30 No magnet detected when teaching in the start or end of the measuring range. • Value below minimum measuring range (< 1 mm). O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...
  • Page 31 Lift your finger. ✓ The switching point is reset. 4 Hz 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
  • Page 32 Lift your finger. ✓ The switching behavior is inverted. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 33: Maintenance

    8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 34: Decommissioning

    The sensor is electronic waste and must under no circumstances be disposed of with general waste. O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK...

  • Page 35: Technical Data

    Load resistance (current ≤500 Ω output) Load resistance (voltage ≥2 kΩ output) 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...

  • Page 36: Ambient Data

    10 ... 55 Hz/1 mm Perm. ambient temperature -20 °C ... +70 °C O P E R A T I N G I N S T R U C T I O N S | MPS-C 8019721.1FIH/2022-06-01 | SICK Subject to change without notice...

  • Page 37: Annex

    (part number: see the entry in the “P/N” or “Ident. no.” field on the type label). 8019721.1FIH/2022-06-01 | SICK O P E R A T I N G I N S T R U C T I O N S | MPS-C Subject to change without notice...
