14
en | Installing
4.2
Unmounting
Notice!
To remove the AMC2-4R4 from a mounting rail, first remove all pluggable connectors.
Push down the AMC2-4R4 until the lower edge snaps out of the mounting rail [1]. Pull the
lower end of the AMC2-4R4 from the mounting rail [2].
Figure 4.2: Unmounting the AMC2 from a mounting rail
2020-01 | V02 |
Installation manual
Access Modular Controller 2
Bosch Access Systems B.V.
