Depending on the kind of interface are available the following constellations are possible:
–
–
–
System configurations for Access Control applications.
–
–
2020-01 | V02 |
Host
Ethernet
Access Controller
a = AMC2-4W
b = AMC2-4R4
AMC2-16ION
I/O-Extensionboards
a = AMC2-16IOE
b = AMC2-8IOE
c = AMC2-16IE
Card reader
Communication and power supply
Using RS-232 host connection one AMC2-4R4 can be connected per COM port.
Using RS-485 host connection, up to eight of these modules can be combined on one
COM port.
Up to three extension boards can be connected to and controlled by the AMC2-4R4.
These can be any combination of types AMC2-8IOE, AMC2-16IOE, or AMC2-16IE.
The minimum configuration consists of:
– one PC with system software,
– one AMC2 controller,
– one AMC power supply,
– one AMC enclosure.
The maximum configuration depends on the system software,
