- Page 1 PRESTON TALL BOOKCASE www.potterybarnkids.com Date: 2014-Sept, 14 Page 1 of 7 Rev:...
- Page 2 Important Safety Instructions: Please read all instructions carefully before assembling this Tall Bookcase. • For your safety, assembly by two or more adults is strongly recommended. • Keep these instructions for future use. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the •...
- Page 3 Tools Required: Philips Head Screwdriver (not included) Power Drill (not included) Drill Bit Φ2mm (not included) Drill Bit Φ6mm (not included) Assembly Instruction Steps: 1. Attach the Left and Right Side Panel (B&C) to the Top Panel (A), by aligning the pre-drilled holes to the exposed wooden dowels, as shown in the illustration below.
- Page 4 8. Attach the Back Panel (F) to the pre-assembled piece and secure with 30 Wood Screws (L), as shown in the illustration below. 9. Insert 16 Shelf Support Pegs (K) into the corresponding holes inside the assembled Bookcase. 10. Place the 4 Adjustable Shelves (E) onto the Shelf Support Pegs, as seen below. Make sure each shelf is stable. 11.
- Page 5 Multiple Bookcases can be combined together by following the assembly instructions below. 12. Place the Left Bookcase down onto the floor, as seen below. 13. Attach the Small Drill Bit Φ2mm (not included) to the Power Drill (not included). 14. From the inside of the bookcase, drill through the pre-drilled holes of the Side Panel in a 90-degree angle, at the locations seen below.
- Page 6 18. Carefully turn the Left and Right Bookcases upright and place the Bookcases in their desired location. Adjust the levelers on the bookcases as needed. 19. Align the bookcases together. 20. Secure with 4 sets of Connecting Screws (O) and Sleeve Nuts (P), as seen below. 21.
- Page 7 25. When connecting the Preston Tall Bookcase to another Preston Media Base or Preston EW Media Base, it is necessary to secure them by using the Metal Bracket (M) with Short Screw (N), as shown below. 26. Assembly is now complete.
- Page 8 FURNITURE TIPPING RESTRAINT WARNING: This product is only a deterrent. It is not a substitute for proper adult supervision. Manufacturer assumes no liability for improper installation or excessive loads placed on screws, brackets or straps. Young children may be injured by tipping furniture and the use of a tipping restraint is highly recommended.
