Assembly Instructions
Assembly Instructions
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
(1) 0119257 Worksurface or
(1) 0119688 Worksurface (with cutout)
(1) 0111446
Modesty Panel
(1) 0111447
Leg
Parts bag with casters
(for lecterns with casters)
(2) 0105662
5/16-18 Stem
Caster
(4) 026073
#8 x 3/4" PHSM
screw
Important
(1) 0111449
Unit-to-Unit Bracket
(1) 0111450
Backer Plate
(3) 052901
(17) 026064
8-32 x 3/8"
1/4-20 x 5/8"
PHMS
PHMS
(1) 025069
Caster / Glide
wrench
Inspiration Plus Side Table
55413
(1) 0111472
Leg
Parts bag with glides
(for lecterns with toe kick)
(2) 037779
(3) 052901
5/16-18 x 1
8-32 x 3/8"
Glide
PHMS
(4) 026073
(1) 025069
Caster / Glide
#8 x 3/4" PHSM
screw
wrench
Phillips
Screwdriver
Caster / Glide
wrench
(included)
(17) 026064
1/4-20 x 5/8"
PHMS
0119685 Page 1 of 4
Advertisement
Related Manuals for Spectrum Industries Inspiration Plus Side Table
Summary of Contents for Spectrum Industries Inspiration Plus Side Table
- Page 1 800-235-1262, 715-723-6750 Thank you for purchasing Spectrum products! Inspiration Plus Side Table (1) 0119257 Worksurface or (1) 0111449 (1) 0119688 Worksurface (with cutout) Unit-to-Unit Bracket...
- Page 2 1. Attach unit-to-unit bracket to lectern 1. The table is symmetrical and can be mounted on the left or right side of the lectern. Determine which side the table will be mounted. 2. Attach the unit-to-unit bracket and the backer plate to the left or right side panel with (3) 1/4-20 x 5/8”...
- Page 3 2. Assemble Table 1. Place the worksurface face down onto a non-abrasive surface. 2. Attach the leg as shown with (8) 1/4-20 x 5/8” PHM screws. Figure 2A. Tighten securely. 3. Attach the (2) casters or (2) glides to the bottom of the leg and tighten securely. 4.
- Page 4 Do not lift up or pull the table-move the table and lectern together. Figure 3B 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM © 2015 Spectrum Industries Inc., All rights reserved. 0119685 Page 4 of 4...
