ASSEMBLY INSTRUCTIONS
KFV
Multi-point locks,
key operated
BS 6000 OF/OR (without latch/without deadbolt)
BS 6000
BS 6600
Window systems
Door systems
Comfort systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KFV BS 6000 OF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siegenia KFV BS 6000 OF

Summary of Contents for Siegenia KFV BS 6000 OF

  • Page 1 ASSEMBLY INSTRUCTIONS Multi-point locks, key operated BS 6000 OF/OR (without latch/without deadbolt) BS 6000 BS 6600 Window systems Door systems Comfort systems...
  • Page 2 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 2/64 02.2019 H39.MFVRS009EN-00...

  • Page 3: Table Of Contents

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Inhalt INSTALLATION BS 6000, BS 6600....32 Change DIN orientation of the INTRODUCTION .........4 soft lock latch ..........32 Manufacturer and Service ......4 Swing door roller latch ........ 33 Target group of this documentation .....

  • Page 4: Introduction

    KFV Karl Fliether GmbH & Co. KG gressive or corrosive components. A company of the SIEGENIA GROUP • Foreign objects and/or materials which impede or Siemensstraße 10 prevent proper use must not be placed within the...

  • Page 5: Transport

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 • Adhere to airgap (interval between faceplate and Symbols used frame parts): The multi-point lock functions safely The following icons are used in this document: with an airgap between 3.5 mm +/- 1.5 mm. Beyond this, the fabricator must ensure that the airgap is General warning symbol large enough to guarantee the freedom from cons-...

  • Page 6: Other Types Of Indicators

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Other types of indicators 1.11 Applicable documents Below is a list of symbols used in these instructions and For the installation of the multi-point lock, it is essential their meanings: to observe all assembly and operating instructions that are enclosed with other (optional) components.
  • Page 7 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 None of the locking elements may be excluded when the door is open. Force must be exerted on the lever handle only in the normal direction of rotation.

  • Page 8: Safety

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Safety hazardous situation. If this hazardous situation is not prevented, it could lead to minor or moderate injuries. • Before starting the assembly work, read the follo- wing safety instructions carefully.

  • Page 9: Personal Protective Equipment

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Personal protective equipment You will need the following protective equipment when assembling multi-point service locks: • Safety shoes • Protective gloves • Protective goggles H39.MFVRS009EN-00 02.2019 9/64...

  • Page 10: Variants And Components

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Variants and components Delivery options The vertical multi-point locks are additionally equipped with an angle gear [5] and a cover angle [6] for vertical locking part in the door frame. Three variants are available: BS 6000 OF/OR [1] without latch and deadbolt in the main lock, BS 6000 [2] with latch and deadbolt in the main lock and BS 6600 [3] with latch and deadbolt and with two auxiliary boxes with round bolt/hook bolt combination.
  • Page 11 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 BS 6000, BS 6600 Use in the active sash H39.MFVRS009EN-00 02.2019 11/64...

  • Page 12: Size Variants Bs 6000, Bs 6000 Of/Or

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Size variants BS 6000, BS 6000 OF/OR 3.2.1 PZ dimensions: 92 mm, 94 mm Size suitable for variants sash rebate height 1810 - 2100 W000 2100 1050 (1810 - 2070*) * with dimension G = 1020...

  • Page 13: Size Variant Bs 6600

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Size variant BS 6600 3.3.1 PZ dimensions: 72 mm, 92 mm Size suitable for variants sash rebate height 1810 - 2100 K600 2100 1050 (1810 - 2070*) * with dimension G = 1020 Dimensions I + K...

  • Page 14: Main Lock Types, Key-Operated

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Main lock types, key-operated Variable dimensions in mm PZ dimen- Deadbolt Cylinder lock sion Backset Rear backset projection Main lock type PZ/RZ 17.5 57.5 12.5 51.5 17.5 57.5 12.5 31.5...

  • Page 15: Angle Gear

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Angle gear Cover angle Auxiliary boxes for BS 6600 42,5 20,5 H39.MFVRS009EN-00 02.2019 15/64...

  • Page 16: Assembly Bs 6000 Of/Or

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Assembly BS 6000 OF/OR Milling the door leaf CAUTION There is a risk of injury from swarf During milling work, there will be swarf flying around at high speed. Without protective equipment, this swarf can cause injuries, especially to the eyes.
  • Page 17 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Cylinders Profile cylinder Round cylinder milling milling [1] Ø 18.0 mm [2] 21.0 mm [3] 12.0 mm [4] Ø 24.0 mm [5] 20.0 mm [E] PZ dimension All dimensions of the main lock, see chapter 3.4 „Main lock types, key-operated“...

  • Page 18: Measure And Crop Reductions

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Measure and crop reductions CAUTION There is a risk of injury from sharp edges Cropping metal components creates sharp edges. This presents a danger of cutting injuries. •...

  • Page 19: Installing The Multi-Point Lock

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the multi-point lock f Insert the multi-point lock wi- thout the angle gear and cover angle into the milled door leaf. Adjust the position to the profile cylinder milling.
  • Page 20 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the main faceplate of the multi-point lock using all screws provided. 20/64 02.2019 H39.MFVRS009EN-00...

  • Page 21: Installing The Angle Gear

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 4.3.1 Installing the angle gear Hold the multi-point lock firmly during the installation. f Remove the two screws at the top end of the faceplate to install the angle gear (top). f Loosen the two bottom screws to such an extent that the mul- ti-point lock can be pulled out...
  • Page 22 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Carefully angle the drive rod away from the face plate. Do not overstretch the drive rod. f Guide the toothed shoe of the angle gear [1] onto the toothed drive rod of the faceplate [2] perpendicularly.
  • Page 23 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Insert the multi-point lock together with the angle gear into the routed pockets and grooves. f Slide the cover plate down- wards over the weld of the angle gear and faceplate.
  • Page 24 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the top part of the faceplate and the angle gear to the door leaf. 24/64 02.2019 H39.MFVRS009EN-00...

  • Page 25: Mounting The Cover Angle

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 4.3.2 Mounting the cover angle f Remove the two screws at the bottom end of the faceplate to mount the cover angle (bot- tom). f Unhinge the multi-point lock from the bottom end of the door leaf.
  • Page 26 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Carefully angle the drive rod away from the face plate. Do not overstretch the drive rod. f Guide the toothed drive rod of the faceplate [1] onto the too- thed shoe of the cover angle [2] perpendicularly.
  • Page 27 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Insert the multi-point lock together with the cover angle into the routed pockets and grooves. f Slide the cover plate upwards over the weld of the cover angle and faceplate.
  • Page 28 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the bottom part of the face- plate and the cover angle to the door leaf. 28/64 02.2019 H39.MFVRS009EN-00...

  • Page 29: Installing The Hardware Components

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the hardware components Prior to the assembly of the hardware, observe the enclosed assembly instructions of the manufacturer. Compare the drilling template for the hardware with the positions of the fixing holes for the gear box before drilling (see chapter 3.4 „Main lock types, key-operated“...

  • Page 30: Frame And Floor Milling

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Frame and floor milling Determination of position, see chapter The frame/ floor parts are horizontally Always wear safety goggles for drilling 3.2 „Size variants BS 6000, BS 6000 adjusted according to the system axis and milling work.

  • Page 31: Installing The Frame And Floor Parts

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the frame and floor parts The frame/ floor parts are horizontally adjusted according to the system axis f Insert the top striker plate and the bottom bushing into the routed pocket of the frame or floor. f Fix the top striker plate and the bottom bushing with all screws provided.

  • Page 32: Installation Bs 6000, Bs 6600

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installation BS 6000, BS 6600 The installation of the BS 6600 multi-point lock is described. The installation of the BS 6600 is equivalent to the BS 6600. The milling and assembly of the auxiliary boxes are omitted for the BS 6000.

  • Page 33: Swing Door Roller Latch

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Swing door roller latch 5.2.1 Replace soft lock latch with swing door roller latch (optional) 1 x 5.5 mm There is a slot [1] on the gear box side.

  • Page 34: Adjustment Of Swing Door Roller Latch

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 5.2.2 Adjustment of swing door roller latch f Align the centre part of the swing door roller latch in such a way that the hole [1] is aligned with the faceplate fixing screws.

  • Page 35: Milling The Door Leaf

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Milling the door leaf CAUTION There is a risk of injury from swarf During milling work, there will be swarf flying around at high speed. Without protective equipment, this swarf can cause injuries, especially to the eyes. •...
  • Page 36 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Auxiliary box (BS 6600) [1] 16.0 mm [2] 42.5 mm + 1 mm [3] 164.0 mm Lever handle and cylinder Lever handle milling Milling Milling [1] Ø 18.0 mm [2] Ø...

  • Page 37: Measure And Crop Reductions

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Measure and crop reductions CAUTION There is a risk of injury from sharp edges Cropping metal components creates sharp edges. This presents a danger of cutting injuries. •...

  • Page 38: Installing The Multi-Point Lock

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the multi-point lock f Insert the multi-point lock wi- thout the angle gear and cover angle into the milled door leaf. Adjust the position to the handle nut. 38/64 02.2019 H39.MFVRS009EN-00...
  • Page 39 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the main faceplate with the auxiliary boxes of the multi- point lock using all screws provided. H39.MFVRS009EN-00 02.2019 39/64...

  • Page 40: Installing The Angle Gear

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 5.5.1 Installing the angle gear Hold the multi-point lock firmly during the installation. f Remove the two screws at the top end of the faceplate to install the angle gear (top). f Loosen the two bottom screws to such an extent that the mul- ti-point lock can be pulled out...
  • Page 41 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Carefully angle the drive rod away from the face plate. Do not overstretch the drive rod. f Guide the toothed shoe of the angle gear [1] onto the toothed drive rod of the faceplate [2] perpendicularly.
  • Page 42 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Insert the multi-point lock together with the angle gear into the routed pockets and grooves. f Slide the cover plate down- wards over the weld of the angle gear and faceplate.
  • Page 43 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the top part of the faceplate and the angle gear to the door leaf. H39.MFVRS009EN-00 02.2019 43/64...

  • Page 44: Mounting The Cover Angle

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 5.5.2 Mounting the cover angle f Remove the two screws at the bottom end of the faceplate to mount the cover angle (bot- tom). f Remove the multi-point lock from the bottom end of the door leaf.
  • Page 45 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Carefully angle the drive rod away from the face plate. Do not overstretch the drive rod. f Guide the toothed drive rod of the faceplate [1] onto the too- thed shoe of the cover angle [2] perpendicularly.
  • Page 46 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Insert the multi-point lock together with the cover angle into the routed pockets and grooves. f Slide the cover plate upwards over the weld of the cover angle and faceplate.
  • Page 47 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Fix the bottom part of the face- plate with the auxiliary box and the cover angle to the door leaf. H39.MFVRS009EN-00 02.2019 47/64...

  • Page 48: Installing The Hardware Components

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the hardware components Prior to the assembly of the hardware, observe the enclosed assembly instructions of the manufacturer. Compare the drilling template for the hardware with the positions of the fixing holes for the gear box before drilling, (see chapter 3.4 „Main lock types, key-operated“...

  • Page 49: Frame And Floor Milling

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Frame and floor milling Determination of position, see chapter The frame/ floor parts are horizontally Always wear safety goggles for drilling 3.3 „Size variant BS 6600“ from page adjusted according to the system axis and milling work.
  • Page 50 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 The cutting dimensions given refer to: E8H striker plate: Main lock Contact the KFV customer service to find out the cutting dimensions for other frame parts or locking rails. Milling for: Q adjustment of the auxiliary boxes...

  • Page 51: Installing The Frame And Floor Parts

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Installing the frame and floor parts The frame/ floor parts are horizontally adjusted according to the system axis. f Insert the top striker plate and the bottom bushing into the routed pockets of the frame. f Fix the top striker plate and the bottom bushing with all screws provided.
  • Page 52 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Insert the striker plates for the main lock and the auxiliary boxes into the routed pockets of the frame. f Fix the striker plates using all screws provided. 52/64 02.2019 H39.MFVRS009EN-00...

  • Page 53: Performing The Adjustments

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Performing the adjustments Adjustment of airgap Observe the assembly and operating instructions for the door hinges. f In accordance with the enclosed assembly instruc- tions of the door hinge manufacturer, adjust the air gap [1] between the faceplate and striker plate or frame.

  • Page 54: Correct The G Adjustment (Top Striker Plate)

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Correct the G adjustment (top striker plate) The G adjustment is performed by moving two eccentric screws [1] laterally by ± 1.5 mm. This lateral adjustment changes the contact pressure of the door on the frame seal.

  • Page 55: Adjustment Of Bottom Bushing

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Adjustment of bottom bushing The adjustment is corrected by -1 to +2 mm via a removable adjustment piece [1]. This adjustment changes the contact pressure of the door on the frame seal.

  • Page 56: Adjustment Of The At Piece

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Adjustment of the AT piece (BS 6000, BS 6600) When the door is closed, the latch must engage in the AT piece with as little play as possible. The AT piece [1] is horizontally adjustable for this purpose.
  • Page 57 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 T 10 2.5 Nm f Tighten the two adjustment screws. f Close the door and check whether the latch engages properly. Day latch T 10 The day latch differs from the AT piece by means of a sliding handle [1], releasable fitting part.

  • Page 58: Correct The Q Adjustment (Bs 6600)

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Correct the Q adjustment (BS 6600) The Q adjustment is performed by moving two eccentric screws [1] laterally by ± 2.5 mm. This lateral adjustment changes the contact pressure of the door on the frame seal.
  • Page 59 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 f Turn the two eccentric screws [1] to the left or right up to 90°. T 10 1.3 Nm f Tighten the three fixing screws of the Q adjustment firmly. f Close the door and lock with a double turn.

  • Page 60: Functional Test

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Functional test A functional disorder in the multi-point lock may result in it no longer being able to open after locking. If a functionality check is performed on a closed door, it may be very difficult to open the door again without causing damage.
  • Page 61 Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Projecting the locking elements f Turn the key in the locking direc- tion with a double turn. The main lock bolt (for BS 6000, BS 6600) and the locking elements must extend into the locking positi- on completely and with ease.

  • Page 62: Check When The Door Is Closed

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Check when the door is closed Checking the engaging of the latch (BS 6000, BS 6600) f Shut the door. The door must close easily. The latch must engage properly in the AT piece.

  • Page 63: Troubleshooting

    Assembly instructions Multi-point locks, key operated BS 6000 OF/OR, BS 6000, BS 6600 Troubleshooting Functional disorder of the lever handle (BS 6000, BS 6600) The lever handle does not return to its original position by itself. f Check that the lever handle is correctly seated. •...
  • Page 64 www.siegenia.com...
