1. General
The Flamco Clean Smart dirt separator is intended for heating and cooling systems with a water or
water-glycol mix (maximum 50%).
The Flamco Clean Smart may be hot during operation.
Minimum and maximum system temperature:
Minimum and maximum system pressure:
Maximum fl ow velocity:
Safety requirements
This product contains a powerful magnet. Care must be taken in the vicinity of pacemakers, data
carriers and other products that are sensitive to magnetism.
Installation and maintenance must be carried out by qualifi ed personnel only.
Observe local regulations and guidelines.

2. Installation

Do not install the product above a suspended ceiling or in the vicinity of electronic installations!
Install the Flamco Clean Smart in a dry location not suscreptible to frost and which is easily
accessible for maintenance purposes. Flush the installation thoroughly before installing the
Flamco Clean Smart.
For optimum effi ciency, the connection diameter of the Flamco Clean Smart must correspond to
the pipe diameter of the system. It is further recommended that the inlet pipe into the device be
a straight pipe having a length of no less than 10 times the nominal pipe diameter. The use of
reducing couplings is not recommended. Installation is possible in horizontal, vertical and inclined
pipes; always position the housing vertically (drain valve at bottom) (fi g. 1). Install the Flamco Clean
Smart in the direction of fl ow in accordance with the arrow shown on the connection housing.
Install the Flamco Clean Smart directly before the boiler in the return line, preferably before the
circulation pump (fi g. 2A, 2B, 2C, 2D).

3. Inspection and maintenance

Perform regular visual inspections.
The dirt that collects in the bottom of the Flamco Clean Smart can be removed with the aid of the
drain valve (fi g. 4). Before draining, remove the magnet (Flamco logo) by pushing it downwards and
removing it (fi g. 3). Replace the magnet after draining.
A hose can be attached to the drain valve as required. Only use the drain valve for draining dirty
system water, never for fi lling or draining the installation (fi g. 5).
Use the Flamco service stickers to note the moment of servicing on the handle of the drain valve
(fi g. 6).
Only carry out maintenance when the system has cooled down, remembering to take account of
the pressure.
4. Dismantling
Depressurise the cooled system and remove the Flamco Clean Smart from the system.
Observe local regulations for disposing of the various parts of the Flamco Clean Smart.
After disassembly, it is not allowed to reinstall the product in another line position.
6
–10 °C to +120 °C.
0.2 bar to 10 bar.
3 m/s.
