Install the Module

Compact I/O is suitable for use in an industrial environment when installed
in accordance with these instructions. Specifically, this equipment is intended
for use in clean, dry environments (Pollution Degree 2
exceeding Over Voltage Category II
Preventing Electrostatic Discharge
ATTENTION
This equipment is sensitive to electrostatic discharge, which can
cause internal damage and affect normal operation. Follow these
guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• If available, use a static-safe workstation.
When not in use, store the equipment in appropriate static-safe
packaging.
If you connect or disconnect the serial cable with power applied
WARNING
to this module or the serial device on the other end of the cable,
an electrical arc can occur. This can cause an explosion in
hazardous locations. Be sure that power is removed or the area is
nonhazardous before proceeding.
(1)
Pollution Degree 2 is an environment where, normally, only non-conductive pollution occurs except
that occasionally a temporary conductivity caused by condensation shall be expected.
(2)
Over Voltage Category II is the load level section of the electrical distribution system. At this level
transient voltages are controlled and do not exceed the impulse voltage capability of the product's
insulation.
(3)
Pollution Degree 2 and Over Voltage Category II are International Electrotechnical Commission (IEC)
designations.
Compact 1769-ASCII Module 5
(2)
(IEC 60664-1).
Publication
1769-IN068B-EN-P - May 2005
(1)
) and to circuits not
(3)
