Description
Module Production Data
8
Pad Character
9 Receive Swap Mode
10 Master Handshake Mode
11 Message Time Out
Serial Port Transmit Data
12 Max Number of Transmit
Characters
13 Transmit Record End Mode
14 Transmit End Delimiter
15 Transmit Swap Mode
Channel 1
16 Serial Character Framing
17 Serial Port Speed
Values
(1) 0...127/255 0...0x7f (0...127) for 7-bit data
0...2
0...1
0...65535
0...200
0...2
(1) 0...127/255 0...0x7f (0...127) for 7-bit data
0...2
0...8
0...7
Compact 1769-ASCII Module 23
Valid Data Values
0...0xff (0...255) for 8-bit data
0 = disabled, 1 = 16-bit, 2 = 32-bit
0 = master/slave handshake, 1 = produce
immediate
0 = none, 1 to 65535 ms
In Simultaneous mode, the total number
of channel 0 characters plus channel 1
characters cannot exceed 200.
0 = ignore, 1 = exclude, 2 = include end
delimiter
0...0xff (0...255) for 8-bit data
0 = disabled, 1 = 16-bit, 2 = 32-bit
0 = 7N2, 1 = 7E1, 2 = 7O1, 3 = 8N1, 4 =
8N2, 5 = 8E1, 6 = 8O1, 7 = 7E2, 8 = 7O2
0 = 9600, 1 = 1200, 2 = 2400, 3 = 4800, 4
= 19200, 5 = 38400, 6 = 57.6k, 7 = 115.2k
(half-duplex only)
