34 Compact 1769-ASCII Module
Value Meaning
(Hex)
Channel 0 Module Errors
430 Data buffer mode
440 Invalid serial port framing
441 Invalid serial port speed
442 Invalid max number of receive
characters
443 Invalid receive record mode
444 Invalid receive start delimiter
445 Invalid receive record end mode
446 Invalid receive record end
delimiter
447 Invalid pad character
448 Invalid receive swap mode
449 Invalid master handshake mode
44A Invalid message timeout
44B Invalid max number of transmit
characters
44C Invalid transmit record end mode The transmit record end mode specified
44D Invalid transmit end delimiter
Publication
1769-IN068B-EN-P - May 2005
Description
0 = alternate mode; 1 = simultaneous
mode. Anything else is invalid.
The serial port framing specified is
invalid.
The serial port speed specified is invalid.
The maximum number of receive
characters specified for channel 0 is too
large.
The receive record mode specified is
invalid.
The receive start delimiter specified is
invalid.
The receive record end mode specified is
invalid.
The receive record end delimiter
specified is invalid.
The pad character specified is invalid.
The receive swap mode specified is
invalid.
The master handshake mode specified is
invalid.
The timeout delay specified is invalid.
The transmit characters specified is
invalid.
is invalid.
The transmit end delimiter specified is
invalid.
