  • Page 1 Installation Instructions CompactLogix EtherNet/IP Web Server Module Catalog Number 1768-EWEB Topic Page Important User Information Minimum Spacing What You Need Install the Modules Wire the Module Connect the Module Configure the Module Confirm Your Installation Remove the EtherNet/IP Web Server Module Troubleshoot the Module Status Indicators Specifications...
  • Page 2: Important User Information

    2 CompactLogix EtherNet/IP Web Server Module mportant User Information Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid-state equipment and hard-wired electromechanical devices.
  • Page 3: North American Hazardous Location Approval

    CompactLogix EtherNet/IP Web Server Module 3 North American Hazardous Location Approval The following information applies Informations sur l’utilisation de cet when operating this equipment in équipement en environnements hazardous locations. dangereux. Products marked "CL I, DIV 2, GP A, B, C, D" are Les produits marqués "CL I, DIV 2, GP A, B, C, D"...
  • Page 4: European Hazardous Location Approval

    4 CompactLogix EtherNet/IP Web Server Module European Hazardous Location Approval This equipment is intended for use in potentially explosive atmospheres as defined by European Union Directive 94/9/EC. Intertek certifies that this equipment has been found to comply with the Essential Health and Safety Requirements relating to the design and construction of Category 3 equipment intended for use in Zone 2 potentially explosive atmospheres, given in Annex II to this Directive.
  • Page 5: Environment And Enclosure

    CompactLogix EtherNet/IP Web Server Module 5 Environment and Enclosure ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
  • Page 6: Prevent Electrostatic Discharge

    6 CompactLogix EtherNet/IP Web Server Module Prevent Electrostatic Discharge ATTENTION: This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. •...
  • Page 7: Minimum Spacing

    CompactLogix EtherNet/IP Web Server Module 7 Minimum Spacing Plan for this minimum spacing from enclosure walls, wireways, and other equipment. Power L2/N 31609-M Item Description 105 mm (4 in.) 90 mm (3.54 in.) Specifications on page for the temperature range. AB Driv Rockwell Automation Publication 1768-IN007B-EN-P - August 2010...
  • Page 8: What You Need

    8 CompactLogix EtherNet/IP Web Server Module What You Need Item Cat. No. or Size 1768 CompactLogix power supply 1768-PA3 1768 CompactLogix controller 1768-L43 1769 end cap 1769-ECR Connects to the controller as the last module, either: • without any 1769-series modules attached to the controller (1768-series only) •...
  • Page 9 CompactLogix EtherNet/IP Web Server Module 9 If You Are Using Screws to Mount Your Modules Do not use screws and DIN rail to mount the modules. It is IMPORTANT possible to break the mounting tabs off if you screw the modules to the panel while they are on DIN rail The steps in these instructions show how to mount the modules on DIN rail.
  • Page 10: Install The Din Rail

    10 CompactLogix EtherNet/IP Web Server Module Install the DIN Rail Mount the DIN rail in a suitable location. ATTENTION: This product is grounded through the DIN rail to chassis ground. Use zinc plated yellow-chromate steel DIN rail to assure proper grounding. The use of other DIN rail materials (for example, aluminum or plastic) that can corrode, oxidize, or are poor conductors, can result in improper or intermittent grounding.
  • Page 11 CompactLogix EtherNet/IP Web Server Module 11 2. Align and press the controller onto the DIN rail until the latches snap closed. Mount the EtherNet/IP Web Server Module on the DIN Rail 1. Open the DIN rail latches on the module. AB Driv 2.
  • Page 12: Mount The Power Supply On The Din Rail

    12 CompactLogix EtherNet/IP Web Server Module 3. Slide module snugly against the controller. Mount the Power Supply on the DIN Rail 1. Close the DIN rail latches on the power supply. 2. Align and press the power supply onto the DIN rail until the latches snap closed.
  • Page 13 CompactLogix EtherNet/IP Web Server Module 13 When the module is in place, the DIN rail latches snap closed. Item Description Locking tab Tongue-and-groove slot 3. Slide the locking tab of the module to the left to lock the module in place.
  • Page 14: Wire The Module

    14 CompactLogix EtherNet/IP Web Server Module 6. Move the lock latch to the left to lock the endcap on the module. Item Description Lock latch Wire the Module Use an RJ45 connector to connect to the EtherNet/IP network. 8 ------ NC 7 ------ NC 6 ------ RD- 5 ------ NC...
  • Page 15: Connect The Module

    CompactLogix EtherNet/IP Web Server Module 15 Connect the Module WARNING: If you connect or disconnect the cable with power applied to this module or any device on the network, an electrical arc can occur. This could cause an explosion in hazardous location installations.
  • Page 16: Configure The Module

    16 CompactLogix EtherNet/IP Web Server Module Configure the Module To configure your module, refer to the configuration chapter of the Web Server Modules User Manual, publication ENET-UM527. Confirm Your Installation Verify the following status indicators’ states. Power L2/N 31608-M Item Description Solid or flashing green Solid green...
  • Page 17: Remove The Ethernet/Ip Web Server Module

    CompactLogix EtherNet/IP Web Server Module 17 Remove the EtherNet/IP Web Server Module When you turn the CompactLogix power supply off, make sure IMPORTANT you wait for all status indicators on the power supply and controller to turn off before disconnecting any part from the system.
  • Page 18: Troubleshoot The Module

    18 CompactLogix EtherNet/IP Web Server Module Troubleshoot the Module The three bi-color (red/green)status indicators on the module provide diagnostic information about the module and its connections to the network. If the alphanumeric display and status indicators do not sequence through the expected states, refer to the troubleshooting tables.
  • Page 19: Status Indicators

    CompactLogix EtherNet/IP Web Server Module 19 Status Indicators The module status indicators provides the following information: Indicator Status Description Module is not powered, or does not have an IP address. • Verify there is chassis power and the module is completely inserted into the chassis and backplane.
  • Page 20: Specifications

    20 CompactLogix EtherNet/IP Web Server Module Specifications Technical Specifications - 1768-EWEB Attribute 1768-EWEB Backplane current 834 mA at 5.2V DC Power consumption 4.34 W Power dissipation 4.38 W Isolation (continuous-voltage 30V, Functional Insulation Type, Ethernet network to system rating) Type tested at 710V DC for 60 s Wire Size Ethernet network connections: RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e...
  • Page 21 CompactLogix EtherNet/IP Web Server Module 21 Environmental Specifications - 1768-EWEB Attribute 1768-EWEB 0…60 °C (32...140 °F) Temperature, operating • IEC 60068-2-1 (Test Ad, Operating Cold) • IEC 60068-2-2 (Test Bd, Operating Dry Heat) • IEC 60068-2-14 (Test Nb, Operating Thermal Shock) -40…85 °C (-40...185 °F) Temperature, nonoperating •...
  • Page 22 22 CompactLogix EtherNet/IP Web Server Module Environmental Specifications - 1768-EWEB Attribute 1768-EWEB Surge transient immunity ±2 kV line-earth(CM) on communication ports • IEC 61000-4-5 Conducted RF immunity 10V rms with 1 kHz sine-wave 80%AM from • IEC 61000-4-6: 150 kHz…80 MHz Enclosure type rating None (open-style) Certifications...
  • Page 23: Additional Resources

    CompactLogix EtherNet/IP Web Server Module 23 Additional Resources These documents contain additional information concerning related Rockwell Automation products. Resource Description EtherNet/IP Modules in Logix5000 Control Provides information about how to use Systems User Manual, publication EtherNet/IP modules with vrious Logix5000 ENET-UM001 controllers.
  • Page 24: Rockwell Automation Support

    Your comments will help us serve your documentation needs better. If you have any suggestions on how to improve this document, complete this form, publication RA-DU002, available at http://www.rockwellautomation.com/literature/. Allen-Bradley, Allen-Bradley, CompactLogix, RSLogix5000, Rockwell Software, Rockwell Automation, and TechConnect are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
