4 Compact 1769-ASCII Module
About the Module
The 1769-ASCII module provides a flexible network interface to a wide
variety of RS-232, RS-485, and RS-422 ASCII devices. The module provides
the communication connections to the ASCII device.
1a
2a
3a
3b
2b
1b
Publication
1769-IN068B-EN-P - May 2005
2a
2b
Item Description
1a
Upper DIN rail latch
1b
Lower DIN rail latch
2a
Upper tongue-and-groove slots
2b
Lower tongue-and-groove slots
4
3a
Channel 0 isolated ASCII
connector
3b
Channel 1 isolated ASCII
connector
4
Stationary bus connector with
male pins
