3 MOUNT
Mechanical Dimensions
Dimensions
A
Drive
Size
mm
in
1
232.0
9. 1 3
2
257.0
10. 1 2
3
310.0
12.20
4
360.0
14. 1 7
Mounting Clearance
Drive Size
All Frame Sizes
Typical drive heat losses are approximately 3% of operating load conditions. Above are guidelines only
NOTE
and the operating ambient temperature of the drive MUST be maintained at all times.
Mounting Bolts & Tightening Torques
Mounting Bolts
Frame Size
All Frame Sizes
D
E
mm
in
mm
189.0
7.44
25.0
200.0
7.87
28.5
251.5
9.90
33.4
300.0
1 1.8
33.4
X Above & Below
mm
200
4 x M4 (#8)
F
in
mm
in
0.98
162.0
6.37
1. 1 2
182.0
7. 1 6
1.31
238.0
9.37
1.31
275.0
10.82
in
7.87
Tightening Torques
Frame Size
All Frame Sizes
Weight
G
Drive
Size
mm
in
161.0
6.34
1
188.0
7.40
2
21 1.0
8.30
3
240.0
9.44
4
Y Either Side
mm
10
Control Terminals
0.8 Nm (7 lb-in)
Weight
kg
Ib
2.5
5.5
3.5
7.7
7.0
15.4
9.5
20.9
in
0.39
Power Terminals
1.5 Nm (13 lb-in)
