15 : 6.Metering

The bottom section of the Power Control Manager in-
terface contains a copy of the LED located on the interface
panel (ref. Chapter 12 : 2.Interface board LED
meters that provide a feedback on system performance.
FIGURE 26: Power Control Manager: metering.

15 : 6.1. LEDs

Ready – When this LED is on the amp is ready and in proper
functioning conditions. When this LED is off the amp is non
functional due to a power fault. This can be either:
f internal: if there is an internal power failure; f
f external: if the amp's load current draw has exceeded
f
the maximum acceptable values set by the current
protection limiters.
E.Save – When this LED is on the amp has entered the en-
ergy save mode, after having detected no input signal for a
selected timespan. The amp's power consumption is mini-
mized by decreasing rails voltage.
Protect – This LED lights when short circuit protection has
acted to prevent amplifier damage. This was caused by the
output current trying to increase above the value set by
the user in the overcurrent protection section. No output is
possible when this LED is on. The amplifier checks every 2
seconds if the short circuit condition is still in place. If not,
the limiting action is interrupted, the LED is turned off and
output is possible again.
Limit – This LED is on every time any limiting action is un-
dertaken by any system limiter.
Temp – When this LED is on, the temperature of the mod-
ule's final stage has gone over the user set limit.
Signal – This LED is on when a signal is detected at the input.
20 | IpalMod | User guide

15 : 6.2. Meter strips

Input (V
attenuation processing: the meter therefore represents the
signal level entering the system before any processing is
chart) and some performed.
Pressure (g/cm
the pressure sensor.
Output (V
underneath the meter strip lights when the measured output
voltage is being clipped to the system's maximum possible
voltage level.
Pk Curr. (A
derneath the meter strip lights when the measured output
peak current rises above the limit set in the current clamp
threshold.
Avg curr. (A
red LED underneath the meter strip lights when the meas-
ured output average current exceeds the limit set in the cur-
rent limiter threshold.
Pk pwr (kVA
Avg pwr (W
underneath the meter strip lights when the measured av-
erage power rises above the limit set in the power limiter
threshold section.
Excursion (mm
respect to the central resting position. The Limit red LED
underneath the meter strip lights when the estimated cone
excursion goes beyond the limit set in the excursion limiter
threshold section.
Temp (°C) – Output stage temperature. The Limit red LED
underneath the meter strip lights when the measured
temperature rises above the limit set in the thermal limiter
threshold section.
Temp2 (°C) – Transducer temperature (external probe needed).
Acou. pwr (W
Avg Rar (Rayls) – Estimated average acoustic impedance.
) – Input peak voltage measured before input gain/
pk
) – Peak pressure level as measured by
2
pk
) – Output voltage peak level. The Limit red LED
pk
) – Peak output current. The Limit red LED un-
pk
) – Root mean square current value. The Limit
rms
) – Peak output power.
pk
) – Average output power. The Limit red LED
avg
) – Peak estimated cone excursion with
pk
) – Estimated average acoustic power.
avg
