Socket 370 pentium iii/celeron cpu card with vga, ethernet x 4 and compactflash type ii card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
POD-6704 series
Socket 370 Pentium
III/Celeron™
®
CPU Card with VGA, Ethernet x 4 and
CompactFlash Type II card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POD-6704 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech POD-6704 Series

Summary of Contents for Advantech POD-6704 Series

  • Page 1 POD-6704 series Socket 370 Pentium III/Celeron™ ® CPU Card with VGA, Ethernet x 4 and CompactFlash Type II card...
  • Page 2 UMC is a trademark of United Microelectronics Corporation. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products please visit our website at: http://www.advantech.com http://www.advantech.com/epc For technical support and service for please visit our support website at: http://www.advantech.com/support...
  • Page 3 • 1 ea. Printer cable (1700260250) • 1 ea. FDD cable (1701340603) Note 1: For detailed contents of the POD-6704 series, please refer to the enclosed CD-ROM or disk (in PDF format). If any of these items are missing or damaged, contact your distributor or sales representative immediately.

  • Page 4: Table Of Contents

    Contents Chapter 1 General Information ........1 1.1 Introduction ................. 2 1.2 Specifications ................3 1.3 Features ..................5 1.4 Board layout: Dimensions ............6 Chapter 2 Installation ............7 2.1 Safety Precautions ............... 8 2.2 Jumpers ..................9 2.3 Connectors ................. 10 2.3.1 Locating Jumpers ...............
  • Page 5 2.5.15 ATX power button (CN26) ..........23 2.5.16 ATX Feature Connector (CN27) ........23 2.5.17 EBX Power Connector (CN28) .......... 24 2.5.18 Mini PCI (CN29) ..............24 2.5.19 System fan (CN30) ............24 2.6 Adding System Memory (DIMM) ..........25 2.6.1 Installing DIMMs ...............
  • Page 6 Appendix A Programming the Watchdog Timer ..... 87 Appendix B Filler .............. 91 Appendix C Pin Assignments .......... 93 C.1 COM1 RS-232 Serial Port (CN1) ..........94 C.2 Serial port2 (CN10) ..............95 C.3 LAN LED connectors (CN2,CN3,CN4,CN5) ......96 C.4 LAN RJ45 connectors (CN6, CN7, CN8, CN9) .......

  • Page 7: Chapter 1 General Information

    General Information This chapter gives background information on the POD-6704. Sections include: • Introduction • Features • Specifications • Board layout and dimensions...

  • Page 8: Introduction

    VGA (AGP) controller, one DIMM slot for up to 512 MB RAM memory and four 10/100Base-T Ethernet controllers. In addition, the POD-6704 series supports a solid state disk (SSD) using a CompactFlash™ Type II disk that is not as vulnerable to the hazards of an industrial computing environment.

  • Page 9: Specifications

    1.2 Specifications Standard SBC functions ® • CPU: Socket 370 supports FCPGA for Intel Pentium III processors up to 1.26 GHz, and Celeron™ processor up to 1.2 GHz • BIOS: Award 256 KB Flash memory, Supports Plug & Play, APM 1.2 Supports Ethernet Boot ROM Supports boot from USB device Supports boot from CD-ROM...
  • Page 10 VGA Interface • Chipset: Intel 815E embedded • Frame buffer: Supports 8/16/32 MB frame buffer with system memory • Display type: CRT • Interface: Direct AGP, Accelerator Graphics Ports 1.0 compliant • Display mode: CRT display supports up to 1280 x 1024 @ 16 bpp, 1024 x 768 @ 16 bpp Ethernet controller functions •...

  • Page 11: Features

    1.3 Features ® ® • Supports Socket 370 Package: FC-PGA for Intel Pentium III/ Celeron™ processor • CPU supports up to 1.26GHz Pentium III with 512K • Intel 815E quality chipset supports 133MHz FSB • Supports CompactFlash Type I/II • Ideal for network security applicances, firewalls, intrusion detection systems •...

  • Page 12: Board Layout: Dimensions

    1.4 Board layout: Dimensions Figure 1-1: POD-6704 (dimensions) POD-6704 User's Manual...

  • Page 13: Chapter 2 Installation

    Installation This chapter tells how to set up the POD-6704 hardware. It includes instructions on setting jumpers, and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 14: Safety Precautions

    2.1 Safety Precautions Follow these simple precautions to protect yourself from harm and your PC from damage. 1. To avoid electric shock, always disconnect the power from your PC chassis before you work on it. Don't touch any components on the CPU card or other cards while the PC is on.

  • Page 15: Jumpers

    2.2 Jumpers The POD-6704 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the function of each of the board’s jumpers. Table 2-1: Jumpers Label Function COM1 RIN Function select COM1 Extra power select COM2 RIN Function select COM2 Extra power select...

  • Page 16: Connectors

    2.3 Connectors On-board connectors link the POD-6704 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors. Table 2-2: Connectors Label Function Serial port 1 LAN1 LED LAN4 LED LAN3 LED...

  • Page 17: Locating Jumpers

    2.3.1 Locating Jumpers B I O S B I O S B I O S B I O S B I O S Figure 2-1: Locating jumpers (component side) Chapter 2 Installation...

  • Page 18: Locating Connectors

    2.3.2 Locating Connectors Figure 2-1: Locating connectors POD-6704 User's Manual...

  • Page 19: Setting Jumpers

    Open Closed Closed 2-3 Chapter 2 Installation...

  • Page 20: Com1 Rin Function Select (J1)

    2.4.1 COM1 RIN Function select (J1) Short pins 1-2 for RIN; short pins 2-3 for external power. Table 2-3: COM1 RIN Function select (J1) external power 2.4.2 COM1 External power select (J2) The J2 jumper can be set for either of two kinds of power supply, +12V, and +5V.

  • Page 21: Com2 Rin Function Select (J3)

    2.4.3 COM2 RIN Function select (J3) POD-6704 has a jumper to select the RIN function for COM2. Set pins 1-2 closed for RIN; set pins 2-3 closed for external power. Table 2-5: COM2 RIN function select (J3) external power 2.4.4 COM2 External power select (J4) The J4 jumper can be set for either of two kinds of power supply, +12V, and +5V.

  • Page 22: Pci Vio Power Select (J5)

    2.4.5 PCI VIO power select (J5) J5 selects the power level for PCI VIO power. Set this jumper with pins 1-2 closed for +5V. Set this jumper with pins 2-3 closed for +3.3V . Table 2-7: PCI VIO power select (J5) +3.3V 2.4.6 Hardware Reset (J7) If you install a reset switch, it should be an open single pole switch.

  • Page 23: Cmos Clear Function (J8)

    2.4.7 CMOS clear function (J8) Warning: To avoid damaging the computer, always turn off the power supply before setting "Clear CMOS". Set the jumper back to normal before turning on the power supply. Table 2-8: CMOS clear (J8) *Normal CMOS data clear * default setting 2.4.8 System LED connector (J10) J10 is for your basic power on indicator.

  • Page 24: Connector (Cn1, Cn10)

    2.5 Installation Caution The following sections tell how to make each connection. In most cases, you will simply need to connect a standard cable. All of the connector pin assignments are shown in Appendix C. Warning! Always completely disconnect the power cord from your chassis whenever you are working on it.

  • Page 25: Usb Connector (Cn11)

    It is designed for Ethernet connectivity. Its four Ethernet ports enable designers to create a broad range of applications including network security systems, firewalls, intrusion detection systems, etc. The medium type can be configured via the RSET8139.EXE program included on the utility disk. (See Chapter 5 for detailed information.) LAN LED connector (CN2,CN3,CN4,CN5) The onboard LED will light up to show the status of the Ethernet.

  • Page 26: Keyboard & Ps/2 Mouse Connector (Cn13)

    2.5.4 Keyboard & PS/2 Mouse Connector (CN13) The POD-6704 board provides a keyboard connector. A 6-pin mini- DIN connector (CN13) on the card mounting bracket supports single-board computer applications. The card comes with an adapter to convert from the 6-pin mini-DIN connector to a standard DIN connector and to a PS/2 mouse connector.

  • Page 27: Irda Connector (Cn17)

    MB) and/or 3.5" (720 KB/1.44/2.88 MB) drives. The card uses a Hirose 20 connector (DF13-20DP-1.25V). 2.5.8 IrDA Connector (CN17) This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through BIOS setup. 2.5.9 CPU Fan Power Supply Connector (CN18) This provides power supply to the optional CPU cooling fan.

  • Page 28: Ide2 Connector (Cn22)

    Wire number 1 on the cable is red or blue, and the other wires are gray. Connect one end to connector CN21 on the CPU card. Make sure that the red (or blue) wire corresponds to pin 1 on the connector (on the right side).

  • Page 29: Compactflash Disk (Cn25)

    Plug the other end of the cable into the Enhanced IDE hard drive, with pin 1 on the cable corresponding to pin 1 on the hard drive. (See your hard drive’s documentation for the location of the connector.) If desired, connect a second drive as described above. Unlike floppy drives, IDE hard drives can connect to either end of the cable.

  • Page 30: Ebx Power Connector (Cn28)

    The ATX adapter cable (optional) is used to connect the POD- 6704 to the ATX power supply. The ATX adapter cable has different connectors at both ends. On one end is the ATX 20-pin (female type) which connects to the (male) ATX power supply source.

  • Page 31: Adding System Memory (Dimm)

    2.6 Adding System Memory (DIMM) You can install anywhere from 64 to 512 MB of SDRAM into your POD-6704 series card. The card is provided with a 168-pin DIMM socket, which accepts 32, 64, 128, 256, or 512 MB 3.3 V power level DIMMs.

  • Page 32: Cpu Installation And Upgrading

    2.7 CPU installation and upgrading 1. If you are upgrading the CPU, remove the old CPU from the socket. If it is difficult to remove, you may find chip lubricant (designed for Flip-Chippin-grid-array devices, FCPGAs) and a chip puller helpful. Both are available at electronics hobby supply stores.

  • Page 33: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 34: Award Bios Setup

    3.1 AWARD BIOS Setup The Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off. 3.1.1 Entering setup Turn on the computer and immediately press <DEL>.

  • Page 35: Standard Cmos Setup

    3.1.2 Standard CMOS setup Choose the “STANDARD CMOS SETUP” option from the INITIAL SETUP SCREEN Menu, and the screen below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. Figure 3-2: CMOS setup screen Chapter 3 Award BIOS Setup...

  • Page 36: Advanced Bios Features

    3.1.3 Advanced BIOS Features The ADVANCED BIOS FEATURES is a submenu from the initial BIOS setup screen. It allows the user to configure the POD-6704 according to his particular requirements. Below are some major items that are provided in the ADVANCED BIOS FEATURES SETUP screen: Figure 3-3: Advanced BIOS Features setup screen Virus Warning...
  • Page 37 Quick Power On Self Test This option speeds up the Power-On Self Test (POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or skips some of the items during the test. When disabled, normal POST procedures assumes.
  • Page 38 Boot Up System Speed High Sets the speed to high Sets the speed to low IDE HDD Block Mode Enabled Enable IDE HDD Block Mode. BIOS will detect the block size of the HDD and send a block command automatically. Disabled Disable IDE HDD Block Mode Gate A20 option...
  • Page 39 System The system will not boot, and access to Setup will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt. Note: To disable security, select PASSWORD SETTING in the main menu.

  • Page 40: Advanced Chipset Features

    3.1.4 Advanced Chipset Features By choosing the “ADVANCED CHIPSET FEATURES” option from the INITIAL SETUP SCREEN Menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the POD- 6704. Figure 3-4: Advanced Chipset Features screen POD-6704 User's Manual...

  • Page 41: Integrated Peripherals

    3.1.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the POD-6704 Series. Figure 3-5: Integrated Peripherals Chapter 3 Award BIOS Setup...

  • Page 42: Power Management Setup

    3.1.6 Power management setup The power management setup controls the CPU cards’ “green” features. The following screen shows the manufacturer’s defaults. Figure 3-6: Power management setup screen Power Management This option allows you to determine if the values in power manage- ment are disabled, user-defined, or predefined.

  • Page 43: Pnp Pci Configuration Setup

    3.1.7 PnP PCI configuration setup By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the POD-6704 Series. Figure 3-7: PCI configuration screen Chapter 3 Award BIOS Setup...

  • Page 44: Pc Health Status

    3.1.8 PC Health Status The PC Health Status screen looks like this. It displays information such as CPU and motherboard temperatures, fan speeds, and core voltage. Figure 3-8: PC Health Status POD-6704 User's Manual...

  • Page 45: Frequency/Voltage Control

    3.1.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the POD-6704. Figure 3-9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 46: Load Optimized Defaults

    ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load automatically when you turn the POD-6704 Series system on. 3.1.11 Set Password To establish, change, or disable the password, choose the “SET PASSWORD”...

  • Page 47: Save & Exit Setup

    Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Disable Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the existing password and press <Enter>. You will see “Confirm Password.”...
  • Page 48 POD-6704 User's Manual...

  • Page 49: Chapter 4 Agp Svga Setup

    AGP SVGA Setup • Introduction • Installation of SVGA driver for - Windows 98 and 2000 - Windows NT...

  • Page 50: Introduction

    4.1 Introduction The POD-6704 has an on-board VGA interface. The specifications and features are described as follows: 4.1.1 Chipset The POD-6704 makes use of the display properties of the Intel 815E AGP/SVGA controller. It supports interlaced and non-interlaced analog monitors (color and monochrome VGA) in high-resolution modes while maintaining complete IBM VGA compatibility.
  • Page 51 To set up dual display under Windows 98, follow these steps: 1. Select “Windows98”, “Control panel”, “Display”, “Settings”. 2. Select “1” for current display, or “2” for second display. 3. Enable “Extend my Windows desktop onto this monitor”. 4. Click “OK”. Figure 4-1: Selecting display settings Chapter 4 AGP SVGA Setup...

  • Page 52: Installation Of Svga Driver

    4.2 Installation of SVGA driver Complete the following steps to install the SVGA driver. Follow the procedures that apply to the operating system that you are using within your POD-6704. Important: The following windows illustrations are examples only. You must follow the instructions which appear on your screen.

  • Page 53: Installation For Windows 98 And 2000

    4.2.1 Installation for Windows 98 and 2000 Insert the disk, or otherwise make the files available to the system, and run setup. Then proceed as directed by the prompts. Chapter 4 AGP SVGA Setup...
  • Page 54 POD-6704 User's Manual...
  • Page 55 Chapter 4 AGP SVGA Setup...
  • Page 56 POD-6704 User's Manual...
  • Page 57 Chapter 4 AGP SVGA Setup...

  • Page 58: Installation For Windows Nt

    4.2.2 Installation for Windows NT Insert the disk, or otherwise make the files available to the system, and run setup. Then proceed as directed by the prompts. POD-6704 User's Manual...
  • Page 59 Chapter 4 AGP SVGA Setup...
  • Page 60 POD-6704 User's Manual...
  • Page 61 Chapter 4 AGP SVGA Setup...

  • Page 62: Further Information

    4.3 Further information For further information about the AGP/SVGA installation in your POD- 6704, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Trident website: www.trid.com Advantech websites: www.advantech.com www.advantech.com.tw POD-6704 User's Manual...

  • Page 63: Chapter 5 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet driver for Windows 98 & 2000 • Installation of Ethernet driver for Windows NT • Further information...

  • Page 64: Introduction

    5.1 Introduction The POD-6704 is equipped with a high performance Intel 82562ET 32-bit Ethernet chipset. This is a highly integrated Platform LAN Connect (ICH2/3/4) device combining 10BASE-T and 100BASE-TX physical layer capabilities. It is fully compliant with the IEEE 802.3/ 802.3u standard.

  • Page 65: Installation For Windows 98 And 2000

    5.2.1 Installation for Windows 98 and 2000 Insert the disk, or otherwise make the files available to the system, and run the executable. Then proceed as directed by the prompts. Chapter 5 PCI Bus Ethernet Interface...
  • Page 66 POD-6704 User's Manual...
  • Page 67 Chapter 5 PCI Bus Ethernet Interface...
  • Page 68 POD-6704 User's Manual...
  • Page 69 Chapter 5 PCI Bus Ethernet Interface...
  • Page 70 POD-6704 User's Manual...
  • Page 71 Chapter 5 PCI Bus Ethernet Interface...
  • Page 72 POD-6704 User's Manual...
  • Page 73 Chapter 5 PCI Bus Ethernet Interface...
  • Page 74 POD-6704 User's Manual...
  • Page 75 Chapter 5 PCI Bus Ethernet Interface...
  • Page 76 POD-6704 User's Manual...

  • Page 77: Installation For Windows Nt

    5.2.2 Installation for Windows NT Insert the disk, or otherwise make the files available to the system, and run the appropriate executable. Then proceed as directed by the prompts. Chapter 5 PCI Bus Ethernet Interface...
  • Page 78 POD-6704 User's Manual...
  • Page 79 Chapter 5 PCI Bus Ethernet Interface...
  • Page 80 POD-6704 User's Manual...
  • Page 81 Chapter 5 PCI Bus Ethernet Interface...
  • Page 82 POD-6704 User's Manual...
  • Page 83 Chapter 5 PCI Bus Ethernet Interface...
  • Page 84 POD-6704 User's Manual...
  • Page 85 Chapter 5 PCI Bus Ethernet Interface...
  • Page 86 POD-6704 User's Manual...
  • Page 87 Chapter 5 PCI Bus Ethernet Interface...
  • Page 88 POD-6704 User's Manual...
  • Page 89 Chapter 5 PCI Bus Ethernet Interface...
  • Page 90 POD-6704 User's Manual...
  • Page 91 Chapter 5 PCI Bus Ethernet Interface...

  • Page 92: Further Information

    5.3 Further information Intel website: http://www.intel.com/design/network/products/lan/controllers/82562.htm Advantech website: www.advantech.com www.advantech.com.tw POD-6704 User's Manual...

  • Page 93: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The POD-6704 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.
  • Page 94 A.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time interval. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 95 After data entry, your program must refresh the watchdog timer by rewriting the I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). The following example shows how you might program the watchdog timer in BASIC: Watchdog timer example program OUT &H443, data REM...
  • Page 96 POD-6704 User's Manual...

  • Page 97: Appendix B Filler

    Filler This appendix is supplied so that we can use the old Appendixes C and D, which are perfectly good, without changing all the references to them that appear in the text. We didn't want anyone to think that we forgot Appendix B.
  • Page 98 This page intentionally left pretty much blank. POD-6704 User's Manual...

  • Page 99: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CRT display connector • Keyboard and mouse connector • External keyboard connector • Main power connectors (EBX/ATX) • IDE connector • RS-232 serial port connector •...

  • Page 100: Com1 Rs-232 Serial Port (Cn1)

    C.1 COM1 RS-232 Serial Port (CN1) Table C-1: COM1 RS-232 serial port Signal SOUT POD-6704 Series Appendix C...

  • Page 101: Serial Port2 (Cn10)

    C.2 Serial port2 (CN10) Table C-2: Serial port2 Signal 1 DCD 2 DSR 3 SIN 4 RTS 5 SOUT 6 CTS 7 DTR 8 RI 9 GND Appendix C Pin Assignments...

  • Page 102: Lan Led Connectors (Cn2,Cn3,Cn4,Cn5)

    C.3 LAN LED connectors (CN2,CN3,CN4,CN5) Table C-3: LAN LED connectors Signal LINKLED ACTLED SPLDLE USERDEFINEDLED POD-6704 Series Appendix C...

  • Page 103: Lan Rj45 Connectors (Cn6, Cn7, Cn8, Cn9)

    C.4 LAN RJ45 connectors (CN6, CN7, CN8, CN9) Table C-4: LAN RJ45 connectors Signal XMT+ XMT- RCV+ RCV- Appendix C Pin Assignments...

  • Page 104: Usb1/Usb2 Connector (Cn11)

    C.5 USB1/USB2 Connector (CN11) Table C-5: USB1/USB2 connector USB1 USB2 USBD0- USBD1- USBDO+ USBD1+ USB_GND USB_GND Chassis GND POD-6704 Series Appendix C...

  • Page 105: Lan1 Box Connector (Cn12)

    C.6 LAN1 box connector (CN12) Table C-6: LAN1 box connector Signal 1 +3.3V 2 ACT_LED 3 RX+ 4 RX- 5 LINK LED 6 TGND 7 USB_GND 8 TGND 9 TX+ Appendix C Pin Assignments...

  • Page 106: Keyboard And Mouse Connnector (Cn13)

    C.7 Keyboard and Mouse Connnector (CN13) Table C-7: Keyboard and mouse connector Signal KBCLK KBDATA MSCLK signal MSDATA signal C.8 Extra keyboard (CN14) Table C-8: Extra keyboard Signal KBCLK KBDATA POD-6704 Series Appendix C...

  • Page 107: Printer Port Connector (Cn15)

    C.9 Printer Port Connector (CN15) 25 23 26 24 Table C-9: Parallel port connector Signal * STROBE * AUTOFD * ERR * INIT SLCTINI * ACK BUSY SLCT * low active Appendix C Pin Assignments...

  • Page 108: Floppy Drive Connector (Cn16)

    C.10 Floppy Drive Connector (CN16) 33 31 ..3 1 34 32 ..4 2 Table C-10: Floppy drive connector Signal Signal RWC# INDEX# MOA# DSB# DSA# MOB# DIR# STEP# TRAK0# RDATA# HEAD# DSKCHG# * low active POD-6704 Series Appendix C...

  • Page 109: Ir Connector (Cn17)

    C.11 IR Connector (CN17) Table C-11: IR connector Signal +5 V C.12 CPU Fan Power Connector (CN18) Table C-12: CPU fan power connector Signal +12 V FAN_DEC Appendix C Pin Assignments...

  • Page 110: Vga Display Connector (Cn19)

    C.13 VGA Display Connector (CN19) Table C-13: CRT display connector Signal Signal HSYNC GREEN VSYNC BLUE S-CLK S-DATA POD-6704 Series Appendix C...

  • Page 111: Ide Connector (Cn21)

    C.14 IDE connector (CN21) Table C-14: Primary IDE connector (CN15) signal signal IDE RESET READY Cable Select (Pull-Low) DACK IRQ14 Cable check Active LED Appendix C Pin Assignments...

  • Page 112: Ide Hard Drive Connector (Cn22)

    DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 IO WRITE IO READ IO CHANNEL READY Cable Select HDACKO* IRQ14 ADDR 1 Reserved ADDR 0 ADDR 2 CS1# CS3# IDE ACTIVE* * low active POD-6704 Series Appendix C...

  • Page 113: Compactflash Card Connector (Cn25)

    C.16 CompactFlash Card Connector (CN25) Table C-16: CompactFlash card connector Signal Signal * CS0 * ATA SEL +5 V * IOCS16 * CD2 * CD1 * CS1 * VS1 * IORD * IOWR * WE INTRQ +5 V * CSEL * VS2 * RESER IORDY...

  • Page 114: Atx Power On/Off Button Connector (Cn26)

    C.17 ATX Power On/Off button connector (CN26) Table C-17:ATX On/Off button connector Signal Power on/off signal C.18 ATX Power Connector (CN27) Table C-18: ATX power connector Signal 5 V SB PS_ON POD-6704 Series Appendix C...

  • Page 115: Atx Power Connector (Cn27)

    C.19 EBX Power Connector (CN28) Table C-19:EBX Power Connector signal +12V C.20 System fan power connector (CN30) Table C-20: System fan power connector Signal 1 +5V 2 GND 3 +12V Appendix C Pin Assignments...
  • Page 116 C.21 Digital I/O connector (CN20) Table C.21 Digital I/O connector (CN20) Signal 1 DIO0 2 DIO2 3 DIO1 4 DIO3 5 GND 6 GND POD-6704 Series Appendix C...

  • Page 117: Appendix D System Assignments

    System Assignments This appendix contains information of a detailed or specialized nature. It includes: • System I/O ports • DMA channel assignments • Interrupt assignments • 1st MB memory map...

  • Page 118: System I/O Ports

    D.1 System I/O Ports Table D-1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 119: Dma Channel Assignments

    D.2 DMA Channel Assignments Table D-2: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available * Audio DMA select 0, 1 or 3 D.3 Interrupt Assignments Table D-3: Interrupt assignments Interrupt# Interrupt source IRQ 0...

  • Page 120: 1St Mb Memory Map

    D.4 1st MB Memory Map Table D-4:1st MB memory map Addr. range (Hex) Device F000h - FFFFh System ROM C800h - EFFFh Expansion ROM C000h - C7FFh System ROM B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused A000h - AFFFh EGA/VGA graphics 0000h - 9FFFh Base memory...
