POD-6552 Intel® Celeron® M 600 SBC with
VGA/LCD and Ethernet
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 POD-6552 all-in-one single board computer
• Mini Jumper (yellow)
• Mini Jumper (black)
Optional
• 1 Startup manual
• CD-ROM or disks for utility, drivers, and manual (in
PDF format)
• Wiring kit for POD-6552
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the POD-6552, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com.tw/support
This manual is for the POD-6552 Series Rev. A1.
Part No. 200K655200
1
POD-6552 Startup Manual
p/n: 1653300100
p/n: 1653302122
p/n:PCM-10586-
K100
1st Edition
May 2005.
Specifications
Standard SBC Functions
• CPU: Intel Celeron M 600 w/o L2 cache. Socket
479(Optional for Celeron M CPU)
• BIOS: Award 4Mbit Flash BIOS
• System memory: 200-pin DDR SODIMM x 1, accepts
DDR 266 128/256/512 MB DRAM
• 2nd cache memory: 0 KB
• Enhanced IDE interface: Two channels support up to
four EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports up to UDMA 100 mode. CFC card
occupies secondary master.
• Optional FDD Interface: Supports up to two FDDs
• Serial ports: Four serial RS-232 ports,
COM1,COM3&COM4: RS-232, COM2: RS-232/422/485
• Parallel port: One parallel port, supports EPP/ECP
mode
• Keyboard/mouse connector: Supports a standard PS/
2 Keyboard and PS/2 Mouse
• Power management: Supports power saving modes
including Normal/Standby/Suspend modes. APM 1.2
compliant
• Watchdog timer: 255 level timer intervals
• USB: Six USB 2.0 compliant universal serial bus ports
• IrDA(Optional): 115Kbps, IrDA 1.0 compliant
• Expansion: One PC/104 connector; Two PCI slots
expansion; ISA with 1*8 bit ISA slot by a PCI to ISA
bridge
Solid State Disk
• Supports CompactFlash Card type I/II
VGA/LCD Interface
• Chipset: Intel 852GM chip integrated
• Frame buffer: Supports 64MB frame buffer with system
memory
• Interface: 4X AGP VGA/LCD interface, Support for 9,
12, 15, 18bit TTL TFT(Optional for 16- or 24-bit DSTN
panel)
• Display mode: CRT Mode: 1024 x 768@16bpp (85Hz);
LCD Modes: 1280 x 1024@16bpp (60Hz), 1024 x
768@16bpp (60Hz)
• LVDS: Supports 1 Channel 18bit LVDS inter-
face(Optional for 2 Channel 2 x 18bit LVDS)
• Dual Independent Display: CRT+LVDS, CRT+TV-Out,
LVDS+TV-Out
Ethernet interface
• Chipset: RealTek 8100BL
• Ethernet interface: IEEE 802.3u 100BASE-T Fast Eth-
ernet compatible
• I/O address switchless setting
• Built-in boot ROM
