Advantech POS-760F Startup Manual

POS-760F Socket 370 SBC For POS
Application
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 POS-760F all-in-one single board computer
• 2 serial port cables
• 1 floppy cable
• 1 UDMA/66 IDE flat cable
• 1 startup manual
• CD-ROM or disks for utility, drivers, and manual (in PDF
format)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the POS-760F, please
refer to the enclosed CD-ROM or disk (in PDF
format).
Note 2: Acrobat Reader is acquired to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
Specifications
Standard SBC Functions
• CPU: Socket 370 for Intel
processor
• BIOS: Award 256 KB Flash memory
• Chipset: VIA 82C693/82C686
• System memory: Two DIMM sockets accept 32 ~ 512
MB SDRAM
• Enhanced IDE interface: Supports up to four EIDE
devices. BIOS auto-detect, PIO Mode 3 or Mode 4,
UDMA/33 transfer, UDMA/66 transfer
For more information on this and other Advantech products,
please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the POS-760F series Rev. A1.
Part No. 2007076001
Printed in Taiwan
(part no. 1701100300)
(part no. 1701340602)
(part no. 1701400453)
® Celeron™/Pentium III
1st Edition
Jan. 2000
• FDD interface: Supports up to two FDDs
• Serial ports: Four serial RS-232 ports, COM1, 3, 4:
RS-232, COM2: RS-232/422/485
• Parallel port: Two parallel ports, supports
SPP/EPP/ECP mode
• Infrared port: Shared with COM2. Transfer rates up to
4 Mbps
• Keyboard/mouse connector: Supports standard
PC/AT keyboard and a PS/2 mouse
• Power management: Supports power saving modes
including Normal/Standby/Suspend modes. APM 1.1
compliant
• Watchdog timer: 62 level timer intervals
• USB: Two universal serial bus ports
Solid State Disk
• Supports one 50-pin socket for CompactFlash™ card
and one socket for one DiskOnChip
VGA/LCD Interface
• Chipset: C&T69000 2 MB SDRAM on chip
• Interface: PCI interface, 64-bit engine
• Display mode: Flat panel displays up to 800 x 600 @
24 bpp, 1024 x 768 @ 16 bpp, CRT monitors up to 800
x 600 @ 24 bpp, 1024 x 768 @ 16 bpp
Ethernet Interface
• Chipset: RTL 8139B
• Ethernet interface: PCI 10/100 Mbps Ethernet.
IEEE 802.3 U protocol compatible
• Connection: On-board RJ-45 connector
• I/O address switchless setting
• Built-in boot ROM
Audio Function (optional)
• Chipset: VIA 82C686
• Audio controller: AC97 version 2.0 compliant
interface
• Audio interface: Microphone in, Line in, CD audio in,
Line out, Speaker L and Speaker R
Mechanical and Environmental
• Dimensions (L x W): 203 x 146 mm (8" x 5.75")
• Power supply voltage: +5 V ±5 %
POS-760F Startup Manual
®
1
