Advantech PCM-3531 Startup Manual

PCM-3531 PCI Graphic card PC/104-plus
Module Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-3531
• 1 Start-up manual
• 1 Utility CD
• Optioanl Accessory
- DVI Cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-3531, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of Adobe.)
Mechanical and Environmental
• Dimensions (L x W): 96 x 90 mm (3.8" x 3.5")
• Weight: 0.08kg
• Operating Temperature: 0 ~ 60°C(32~140°F)
• Storage temperature: -40 ~ 85°C(-40~185°F)
• Operating Humidity: 0%~90% relative humity,
non-condensing
• Power Supply Voltage: 5V and 12V
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-3531 series Rev. A2.
Part No. 2006353101
• Chipset: ATI RAGE Mobility M6 chipset
• Video Memory: 8MB on chip
• VGA/LCD Function: Support CRT display, 2 Chan-
nels 18/24-bit LVDS, TV-out, DVI interface
• Dual display combination: LVDS+CRT, LVDS+TV-
out, LVDS+DVI, LVDS+CRT+TV, LVDS+CRT+DVI
p/n 1700000243
• External Power: +12V for LCD inverter
Supports 18/24/36/48 bit LVDS Panel up to
2048x1536 resolution
Support TV-Output (up to 1024x768)
Support 2 Channels 18/24-bit LVDS
Support Hardware MPEG-2 Decoder
Support Dual display function
Compatible with PC/104-plus and standard PCI card
PCI2.1
2nd Edition
Aug. 2006
Specifications
Features
PCM-3531 Startup Manual 1
