PCM-3526 TFT to VGA Module
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-3526
• 1 Startup manual
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-3526, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html(Acrobat is a trademark of Adobe.)
Mechanical and Environmental
• Dimensions (L x W): 72 x 62 mm (3.8" x 3.5")
• Weight: 30g
• Operating Temperature: 0 ~ 60°C(32~140°F)
• Storage temperature: -40 ~ 85°C(-40~185°F)
• Operating Humidity: 0%~90% ralative humity,
non-condensing
• Power Supply Voltage: 5V or 12V
• Power Requirements: 6 ~ 12V @600mA (9V Recom-
mended)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-3526 series Rev. A1.
Part No. 2006352600
1
PCM-3526 Startup Manual
Specifications
• Chipset: Analog Devices ADV7123KST140
• TFT Input: 24,18bit TFT
• VGA output: 15-pin D-SUB VGA output
• Resolution :1024 x 768, 800 x 600, 640 x 480
• TFT Conector: Hirose or Pin Header
• External Power: +5V, +12V
• Connector ESD Keypad connector for OSD control
• LCD connector Hirose or pin header
• Touch Screen Supported
Features
VGA to TFT panel transfer module
Touch Screen and OSD (cable optional) support
Suitable for TFT LCD Panel Adapter
1st Edition
Sep. 2004
P/N:2006352600
