Advantech PCA-5610 Startup Manual

PCA-5610 Industrial VGA card
with ATi Rage Mobility
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCA-5610 Industrial VGA card
• 1 PCA-5610 Startup Manual
• 1 CD with driver utility
• 1 S-VHS cable (optional)
• 1 AV cable (optional)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/readstep2.html
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/nc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCA-5610 series Rev. A1.
Part No. 2002561000
Printed in Taiwan
™
M1
Specifications
Industrial VGA card specifications
• GPU: ATi Rage Mobility™ M1
• Bus: PCI 2.1
• Memory: On-Chip 64Bit 125MHz 8MB SDRAM
• CRT output: 1280x1024 24bpp
• TV-Out Output: S-Video port and optional Composite port;
1024x768 24bpp, 800x600 and 16:9
• LVDS Output: Dual 112MHz LVDS interface; 1280x1024 @ 60Hz
and 800x600 @85Hz, shared with LCD Panel
p/n: 1700000136
• Digital (TTL) Output: Color TFT panel up to 1280x1024, 24-bit
per pixel, single pixel per clock; shared with LVDS
p/n: 1700000137
• Dual Display Mode: CRT, LCD/LVDS; TV, LCD/LVDS; CRT, TV
• Triple-DAC Mode: CRT=TV, LCD/LVDS; LCD/LVDS=TV, CRT;
LCD/LVDS=CRT, TV
Software Installation
• The CD disc contains a driver installer program that will
lead you through the installation of your VGA card.
1st. Edition
March 2004
PCA-5610 Startup Manual 1
