PCA-6005-B
Full-sized PCI-bus
socket 478 Pentium 4/Celeron
processor-based CPU card
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCA-6005-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PCA-6005-B

Summary of Contents for Advantech PCA-6005-B

  • Page 1 PCA-6005-B Full-sized PCI-bus socket 478 Pentium 4/Celeron processor-based CPU card User’s Manual...
  • Page 2 SiS is a registered trademark of Silicon Integrated Systems Corp. Realtek is a trademark of Realtek Semiconductor Corporation All other product names or trademarks are properties of their respective owners. Part No. 2002600531 2nd. Edition Printed in Taiwan April 2004 PCA-6005-B User’s Manual...
  • Page 3 Our dealers are well trained and ready to give you the support you need to get the most from your Advantech products. In fact, most prob- lems reported are minor and are able to be easily solved over the phone.
  • Page 4 PCA-6005-B User’s Manual...
  • Page 5 Product warranty Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products...

  • Page 6: Initial Inspection

    6005-B mechanically and electrically before shipment. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6005-B, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 7: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................3 General Specifications............4 1.3.1 System................4 1.3.2 Memory................4 1.3.3 Input/Output..............4 1.3.4 VGA interface..............5 1.3.5 Ethernet LAN..............5 1.3.6 Ultra 160 SCSI..............5 1.3.7 Industrial features ............5 1.3.8 Mechanical and environmental specifications....
  • Page 8 3.4.16 Video BIOS Shadow............. 33 Advanced Chipset Features..........34 Figure 3.3:Advanced chipset features screen ....34 3.5.1 Advanced DRAM control 1.......... 35 3.5.2 Prefetch Caching............35 3.5.3 System BIOS Cacheable..........35 3.5.4 Video RAM Cacheable..........35 PCA-6005-B User’s Manual viii...
  • Page 9 3.5.5 Memory Hole..............36 3.5.6 AGP Aperture Size ............36 3.5.7 Graphic Window WR Combination ......36 Integrated Peripherals............36 Figure 3.4:Integrated peripherals........36 3.6.1 SiS OnChip IDE Device ..........37 3.6.2 SiS OnChip PCI Device..........38 3.6.3 Onboard Super IO Device..........39 3.6.4 IDE HDD Block Mode ..........
  • Page 10 Table B.2:Floppy drive connector (CN3) ....103 Parallel Port Connector (CN4) ........104 Table B.3:Parallel port connector (CN4)....104 USB Connector (CN6) ..........105 Table B.4:USB1/USB2 connector (CN6)....105 VGA Connector (CN7) ..........106 Table B.5:VGA connector (CN7)....... 106 PCA-6005-B User’s Manual...
  • Page 11 Keyboard and Mouse Connnector CN11)..... 107 Table B.6:Keyboard and mouse connector (CN11)..107 External Keyboard Connector (CN12)......107 Table B.7:External keyboard connector (CN12) ..107 IR Connector (CN13) ............ 108 Table B.8:IR connector (CN13)........108 CPU Fan Power Connector (CN14) ......108 Table B.9:CPU fan power connector (CN14).....
  • Page 12 PCA-6005-B User’s Manual...
  • Page 13 General Information This chapter gives background infor- mation on the PCA-6005-B. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Introduction • Features • Specifications •...

  • Page 14: Chapter 1 General Information

    Ultra 160 SCSI, and two 184-pin DIMM slots for a total of 2 GB DDR SDRAM memory. The remote management inter- face enables the PCA-6005-B to be managed through Ethernet when it is connected to the SNMP-1000 Remote HTTP/SNMP System Manager.

  • Page 15: Features

    CPU fan, CPU temperature and system voltages levels are moni- tored to ensure stable operation. proper system configuration and management. A remote monitoring interface is reserved for remote management through Ethernet by using Advantech's SNMP-1000 system management module. ATX soft power switch: Through the BIOS, the power button can be defined as the "Standby"...

  • Page 16: General Specifications

    • Keyboard and PS/2 mouse connector: A 6-pin mini-DIN connector is located on the mounting bracket for easy connection to a keyboard or PS/2 mouse. An onboard keyboard pin header connector is also avail- able • ISA bus: No ISA bus support PCA-6005-B User’s Manual...

  • Page 17: Vga Interface

    • USB 2.0: Up to 4 USB2.0 ports, availble on the I/O bracket (PCA- 6005E2 and PCA-6005F) or through an optional USB cable, P/N: 1700100170. NOTE: The USB ports operate at USB1.1 speed only under Windows 98/ME. • AC-97 Audio: PCA-6005 can provide audio function. (Require the optional audio extension module PCA-AUDIO-00A1) 1.3.4 VGA interface •...

  • Page 18: Jumpers And Connectors

    1.4 Jumpers and Connectors Connectors on the PCA-6005-B board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application. The tables below list the function of each of the board jumpers and connectors.

  • Page 19: Table 1.3:Scsi Daughter Board

    CN20 ATX feature connector CN21 ATX soft power switch CN27 Extension I/O board connector CN28 Extension I/O board connector CN29 External SM bus connector (for SNMP-1000) CN30 External PCI extension connector CN31 USB port 0, 1 CN32 USB port 2, 3 CN33 PS/2 mouse connector CN34...

  • Page 20: Board Layout: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations Figure 1.1: Board Layout: Jumper and Connector Locations PCA-6005-B User’s Manual...
  • Page 21 Figure 1.2: SCSI daughter board layout Figure 1.3: I/O connectors on bracket...

  • Page 22: Safety Precautions

    OFF) a jumper, you remove the clip. Sometimes a jumper consists of a set of three pins, labeled 1, 2, and 3. In this case you connect either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when setting jumpers. PCA-6005-B User’s Manual...

  • Page 23: Cmos Clear (J1)

    1.7.2 CMOS clear (J1) The PCA-6005-B CPU card contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set J1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 24: System Memory (S1)

    1.8 System Memory (S1) The PCA-6005-B has two sockets for 184-pin dual inline memory mod- ules (DIMMs). All these sockets use 2.5 V unbuffered double data rate synchronous DRAMs (DDR SDRAM) are available in capacities of 128, 256, 512 and 1024 MB. The sockets can be filled in any combination with DIMMs of any size, giving a total memory size between 128 MB and 2 GB.

  • Page 25: Memory Clock Setting (S1)

    1.8.2 Memory clock setting (S1) Table 1.7: Memory Clock Setting Table CPU Clock DDR Clock (Frequency) 100 MHz 100 MHz (400 MHz) (200 MHz) 100 MHz 133 MHz (400 MHz) (266 MHz) 100 MHz 166 MHz (400 MHz) (333 MHz) 133 MHz 100 MHz (533 MHz)

  • Page 26: Cache Memory

    CPU is installed, the lever should snap into place at the side of the socket. Note: To remove a CPU, pull the lever out to the side a little and raise it as far as it will go. Lift out the CPU. PCA-6005-B User’s Manual...
  • Page 28 PCA-6005-B User’s Manual...
  • Page 29 Peripherals This chapter tells how to connect peripherals, switches and indicators to the PCA-6005-B board. You can access most of the connectors from the top of the board while it is installed in the chassis. If you have a number of cards...

  • Page 30: Chapter 2 Connecting Peripherals

    1 on the hard drive connector, which is labeled on the drive circuit board. Check the documentation that came with the drive for more information. Connect the second hard drive to the remaining connector (CN2 or CN1), in the same way as described above. PCA-6005-B User’s Manual...

  • Page 31: Floppy Drive Connector (Cn3)

    2.2 Floppy Drive Connector (CN3) You can attach up to two floppy disk drives to the onboard connector. You can use any combination of 5.25" (360 KB / 1.2 MB) and/or 3.5" (720 KB / 1.44/2.88 MB) drives. The card comes with a 34-pin daisy-chain drive connector cable.

  • Page 32: Usb Port (Cn6)

    The USB interface can be disabled in the system BIOS setup. 2.5 VGA Connector (CN7) The PCA-6005-B includes an AGP SVGA interface that can drive a stan- dard CRT display. CN7 is a standard 15-pin D-SUB connector commonly PCA-6005-B User’s Manual...

  • Page 33: 10/100Base-T Ethernet Connector (Cn8 And Cn34)

    10/100Base-T RJ-45 operation. 2.7 Serial Ports (CN9: COM1; CN10: COM2) CN10 The PCA-6005-B offers two serial ports, CN9 as COM1 and CN10 as COM2. These ports can connect to serial devices, such as a mouse or printers, or to a communication network...

  • Page 34: Ps/2 Keyboard/Mouse Connector (Cn11/Cn33)

    PS/2 keyboard and a PS/2 mouse, respec- tively. CN11 can also be connected to an adapter cable (P/N: 1700060202, available from Advantech) for connecting to both a PS/2 keyboard and a PS/2 mouse. PCA-6005-B User’s Manual...

  • Page 35: External Keyboard Connector (Cn12)

    2.9 External Keyboard Connector (CN12) CN12 In addition to the PS/2 keyboard connector on the PCA-6005-B's rear plate, there is also an extra onboard external keyboard connector. This gives system integrators greater flexibility in designing their systems. 2.10 CPU Fan Connector (CN14) CN14 This connector supports a cooling fan with tachometer output.

  • Page 36: Keyboard Lock And Power Led (Cn16)

    2.11.2 External speaker (CN17) CN17 is a 4-pin connector for an extenal speaker. If there is no external speaker, the PCA-6005-B provides an onboard buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed. 2.11.3 Reset (CN18) Many computer cases offer the convenience of a reset button.

  • Page 37: Connecting To Snmp-1000 Remote Manager

    5V stand-by. 2.13 4-pit Auxiliary power connector (CN46 & ATX1) To supply adequate 12V power to the CPU card, the PCA-6005-B pro- vides two auxiliary power connectors, CN46 and ATX1. CN46 accepts a standard device power connector, and ATX1 accepts 4-pin ATX 12V connector.

  • Page 38: Audio Interface (Cn43)

    2.14 AC-97 Audio interface (CN43) The PCA-6005-B provides AC-97 audio through PCA-AUDIO-00A1 module from Advantech. PCA-6005-B User’s Manual...
  • Page 39 Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 40: Chapter 3 Award Bios Setup

    "CMOS checksum error..." display screen mes- sage appearing. Then enter the "Setup" screen to modify the data. If the "CMOS checksum error..."message appears again and again, please check to see if you need to replace the battery in your system. PCA-6005-B User’s Manual...

  • Page 41: Entering Setup

    3.2 Entering Setup Turn on the computer and press <Del> to allow you to enter the BIOS setup. Figure 3.1: Award BIOS Setup initial screen...

  • Page 42: Standard Cmos Setup

    Choose the “Standard CMOS Features” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. PCA-6005-B User’s Manual...

  • Page 43: Advanced Bios Features

    3.4 Advanced BIOS Features The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the CPU card according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 44: Cpu L2 Cache Ecc Checking

    Setup will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt. PCA-6005-B User’s Manual...

  • Page 45: Apic Mode

    Note: To disable security, select “PASSWORD SET- TING” in the main menu. At this point, you will be asked to enter a password. Simply press <Enter> to disable security. When security is disabled, the system will boot, and you can enter Setup freely.

  • Page 46: Advanced Chipset Features

    CPU card, as shown in Figure 3-5: . Note: DRAM default timings have been carefully cho- sen and should ONLY be changed if data is being lost. Please first contact technical support Figure 3.3: Advanced chipset features screen PCA-6005-B User’s Manual...

  • Page 47: Advanced Dram Control 1

    3.5.1 Advanced DRAM control 1 This item allows you to control the DRAM speed. 3.5.1.1 System performance This item should be set at "Normal Mode" to ensure system stabil- ity. 3.5.1.2 CAS Latency Setting This item is used to adjust the CAS latency. Default setting is 2.5T. 3.5.1.3 DRAM Addr/Cmd Rate This item is set at "AUTO".

  • Page 48: Pca-6005-B User's Manual

    AGP without any translation. The Choice: 4M, 8M, 16M, 32M, 64M, 128M, 256M. 3.5.7 Graphic Window WR Combination This item allows to combine Graphic Window Write. Default is "Dis- abled." 3.6 Integrated Peripherals Figure 3.4: Integrated peripherals PCA-6005-B User’s Manual...

  • Page 49: Sis Onchip Ide Device

    3.6.1 SiS OnChip IDE Device Press Enter to set the internal IDE controller. 3.6.1.1 IDE Primary Master/Slave PIO/UDMA Mode, IDE Secondary Master/Slave PIO/UDMA Mode (Auto) Each channel (Primary and Secondary) has both a master and a slave, making four IDE devices possible. Because each IDE device may have a differ- ent Mode timing (0, 1, 2, 3, 4), it is necessary for these to be independent.

  • Page 50: Sis Onchip Pci Device

    Enable USB 2.0, default is "Enabled." 3.6.2.4 USB Keyboard Support Enable USB keyboard, default is "Enabled." 3.6.2.5 USB Mouse Support Enable USB Mouse, default is "Disabled." 3.6.2.6 SIS AC97 AUDIO If the AC-97 audio function is required, set this item to "Enabled." PCA-6005-B User’s Manual...

  • Page 51: Onboard Super Io Device

    3.6.3 Onboard Super IO Device Press enter to set up the on board super I/O device. 3.6.3.1 Onboard FDC Controller When enabled, this field allows you to connect your floppy disk drives to the onboard floppy disk drive connector instead of a separate controller card.

  • Page 52: Ide Hdd Block Mode

    The LAN boot ROM for boot on LAN function can be enabled or dis- abled. 3.6.6 Init Display First This item allows you to choose which one to activate first, PCI Slot or AGP. The choices: PCI Slot, AGP. PCA-6005-B User’s Manual...

  • Page 53: Power Management Setup

    3.7 Power Management Setup The power management setup controls the CPU card’s “green” features to save power. The following screen shows the manufacturer’s defaults: Figure 3.5: Power management setup screen 3.7.1 ACPI function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI).

  • Page 54: Suspend Mode

    5, 7, 9, 10, 11, Auto. 3.7.7 HDD Off After This item allows you to enable HDD Off After function.Default is "Dis- abled." 3.7.8 Power Button Override This item allows you to select Power Button Override. 3.7.9 Power-Supply Type Choice: AT, ATX PCA-6005-B User’s Manual...

  • Page 55: Power State Resume Control

    3.7.10 Power State Resume Control This field lets you to determine the state that your computer returns after a power failure. If sets to Off, the PC will not boot after a power failure. If sets to On, the PC will restart after a power failure. If sets to Auto, the PC will go back to the previous state before a power failure occurred.

  • Page 56: Pnp/Pci Configurations

    3.8.1 Reset Configuration Data. Note: This is left “Disabled.” Select “Enabled” to reset Extended System Configuration Data (ECSD) if you have installed a new add-on and your OS won’t boot and you need to reconfigure Figure 3.7: PnP/PCI configurations screen PCA-6005-B User’s Manual...

  • Page 57: Pc Health Status

    3.9 PC Health Status Figure 3.8: PC health status screen 3.9.1 VCORE This shows CPU's core voltage : +2.5/ +3.3V/ + 5V/ +12V. 3.9.2 CPU Temperature This shows you the current CPU temperature. 3.9.3 CPU FAN This shows you the current CPU FAN speed.

  • Page 58: Spread Spectrum Control

    3.10.1 Spread Spectrum This item allows you to enable spread spectrum function. Default is "Dis- abled." Figure 3.9: Spread spectrum control screen 3.11 Load Optomized Defaults “LOAD SETUP DEFAULTS” loads the values required by the system for maximum performance. PCA-6005-B User’s Manual...

  • Page 59: Set Password

    3.12 Set Password To change the password: Choose the “Set Password” option from the “Initial Setup Screen” menu and press <Enter>. The screen will display the following message: Enter Password: Press <Enter>. If the CMOS is good or if this option has been used to change the default password, the user is asked for the password stored in the CMOS.
  • Page 60 PCA-6005-B User’s Manual...
  • Page 61 AGP SVGA Setup The PCA-6005-B features an integrated high performance VGA interface. This chapter provides instructions for installing and operating the software drivers on the display driver CD included in your package. Chapter 4...

  • Page 62: Chapter 4 Agp Svga Setup

    The enhanced display drivers for the PCA-6005-B board are located on the software installation CD. You must install the drivers and utility software by using the supplied SETUP pro- gram for DOS drivers.

  • Page 63: Vga Installation

    4.3 VGA Installation First, insert CD drive. Then follow the Icons for your PCA Series model number. Click on the right driver for the auto-installation. The installation programm will guide you through the whole installation process. Follow the instruction when necessary. Chapter 4...
  • Page 64 PCA-6005-B User’s Manual...
  • Page 65 LAN Configuration The PCA-6005-B features an onboard LAN interface. This chapter gives detailed information on Ethernet con- figuration. It shows you how to config- ure the card to match your application requirements. Chapter 5...

  • Page 66: Chapter 5 Lan Configuration

    Chapter 5 LAN Configuration 5.1 Introduction The PCA-6005-B features an optional single/dual 32-bit 10/100 Mbps Ethernet network interface. This interface supports bus mastering archi- tecture and auto-negotiation features. Therefore standard twisted-pair cabling with RJ-45 connectors for both 10 Mbps and 100 Mbps connec- tions can be used.

  • Page 67: Driver Installation

    5.3 Driver Installation The PCA-6005-B's onboard Ethernet interface supports all major network operating systems. The BIOS automatically detects the LAN while booting, and assigns an IRQ level and I/O address. No jumpers or switches are required for user configuration. The drivers and installation instructions are located in the following directories of the utility CD: •...

  • Page 68: Windows 9X Drivers Setup Procedure

    Then click on the "Control Panel" icon to select "System". In the "System Properties" window, select the "Device Manager" tab. Select "View devices by type", and navigate to: Com- puter\Other devices\PCI Ethernet Controller. Highlight "PCI Ether- net Controller" and click on "Properties". PCA-6005-B User’s Manual...
  • Page 69 In the "PCI Ethernet Controller Properties" window, select the "Driver" tab. Then click on "Update Driver...". In the "Update Device Driver Wizard" window, click on "Next". Click "Next". Chapter 5...
  • Page 70 In the following "Update Device Driver Wizard" window, select"Specify a location:". Type in: "D:\Drv_LAN\RTL8139C\WIN98".Then click on "Next". In the following "Update Device Driver Wizard" window, click on "Next". PCA-6005-B User’s Manual...
  • Page 71 When the "Insert Disk" window appears, insert the utility CD into the CD-ROM drive. Then click on "OK". When the "Update Device Driver Wizard" window shows, click on finish. In the "System Settings change" window, select click on "Yes". Chapter 5...

  • Page 72: Windows 2000 Drivers Setup Procedure

    Note: The CD-ROM drive is designed as "E" through- out this section. In the "Windows 2000" screen, click on " Start" and select " set- tings". Then click on the " Control Panel" icon to select "system". PCA-6005-B User’s Manual...
  • Page 73 In the " System Properties" window, select the " Device Manager". In "Device Manager" screen, follow the screen instructions, to click on "Properties". Chapter 5...
  • Page 74 In the following screen, to click on "Update Driver". Click on "Next". PCA-6005-B User’s Manual...
  • Page 75 Following the highlighted item, and click on "Next". Click on "Have Disk". Chapter 5...
  • Page 76 Key in "E:\Drv__LAN\RTL8139C\WIN2000", then click on "OK". To highlight the following item, and click "Next". Click "Next". PCA-6005-B User’s Manual...
  • Page 77 Click "Finish" to complete the installation. Chapter 5...
  • Page 78 PCA-6005-B User’s Manual...
  • Page 79 SCSI Setup and Con- figuration The PCA-6005-B features an onboard SCSI interface. This chapter provides basic SCSI concepts and instructions for installing the software drivers with the SCSI driver disks/CD included in your package...

  • Page 80: Chapter 6 Scsi Setup And Configuration

    Chapter 6 SCSI Setup and Configuration 6.1 Introduction The PCA-6005-B is equipped with an Adaptec AIC-7899 single-chip PCI- to-SCSI host adapter which provides a dual channel Ultra 160 multi- tasking interface between your computer.s PCI bus and SCSI devices (disk drives, CD-ROM drives, scanners, tape backups, removable media drives, etc.).

  • Page 81: Scsi Ids

    A SCSI bus is an electrical pathway that consists of a SCSI interface installed in a computer and one or more SCSI devices. SCSI cables are used to connect the devices to the SCSI interface. For the SCSI bus to function properly, a unique SCSI ID must be assigned to the SCSI inter- face and each SCSI device connected to it, and the SCSI bus must be properly terminated.

  • Page 82: Terminating The Scsi Bus

    If you use a dif- ferent kind of terminator plug, the data I/O rate will decrease. By default, termination on the SCSI controller itself is set to Automatic (the preferred method). We recommend that you do not change this default setting. PCA-6005-B User’s Manual...

  • Page 83: Configuring The Scsi Interface With Scsiselect

    6.5 Configuring the SCSI interface with SCSISelect SCSISelect, included with the CPU card, enables you to change SCSI set- tings without opening the computer. SCSISelect also enables you to low- level format or verify the disk media of your SCSI hard disk drives. The following table lists the available and default settings for each SCSISelect option.
  • Page 84 Host Adapter BIOS Enabled Enabled Disabled : Not Scan Disabled: Scan Bus Domain Validation2 Enabled, Disabled Enabled Support Removable Disabled Disabled Disks Under BIOS as Boot Only, Fixed Disks2 All Disks BIOS Support for Enabled, Disabled Enabled Bootable CD_ROM2 PCA-6005-B User’s Manual...

  • Page 85: Starting Scsiselect

    BIOS Support for Enabled, Disabled Enabled Int 13 Extensions2 1 Setting is valid only if Multiple LUN Support is enabled. 2 Settings are valid only if host adapter BIOS is enabled. 6.6 Starting SCSISelect Follow these steps to start SCSISelect: Turn on or restart your system.
  • Page 86 160 MBytes/sec. • Initiate Wide Negotiation-(Default: Yes) When set to Yes, the SCSI card attempts 16-bit data transfer (wide negotiation.) When set to No, the SCSI card uses 8-bit data transfer unless the SCSI device requests wide negotiation. PCA-6005-B User’s Manual...
  • Page 87 Note: Set Initiate Wide Negotiation to NO if you are using an 8-bit SCSI device that hangs or exhib- its other performance problems with 16-bit data transfer rate enabled. • Enable Disconnection-(Default: Yes) When set to Yes, allows the SCSI device to disconnect from the SCSI bus. Leave the setting at Yes if two or more SCSI device is connected, changing the setting to No results in slightly better performance.
  • Page 88 SCSI bus and sets transfer rates accordingly. Displays the resulting data transfer rate. • Support Removable Disks Under BIOS as Fixed Disks. (Default: Disabled) Determines which removable-media drives are supported by the SCSI card BIOS. Choices are as follows: PCA-6005-B User’s Manual...

  • Page 89: Using Scsi Disk Utilities

    • Disabled. No removable-media drives are treated as hard disk drives. Software drivers are required because the drives are not controlled by the BIOS. • Boot Only.Only the removable-media drive designated as the boot device is treated as a hard disk drive. •...

  • Page 90: Installation Under Windows 2000

    Then it enter SCSI installation. Please insert SCSI driver floppy disk. 6.9 Windows 9X Driver setup procedure In the window 9x screen, click on “start” and select “setting”. Then click on the “Control Panel” icon to select .System. PCA-6005-B User’s Manual...
  • Page 91 In the “System properties”, choose “PCI SCSI Bus Controller.” Then click on “Properties.” Click on "Update Driver"...
  • Page 92 Click on “Next” Recommend to search for a better driver PCA-6005-B User’s Manual...
  • Page 93 If the SCSI driver is supplied in floppy disk, click on “Floppy disk drives.” Then, click on “Next.” If the SCSI driver is supplied in CD-ROM disk, click on “Specify a location:" then enter "E:\Drv_SCSI\AIC7899\Windows\Win9X" In the "Update Device Driver Wizard" click on "Next."...
  • Page 94 The installation is completed. Click on "Finish." Click on "Yes" to restart the system. PCA-6005-B User’s Manual...
  • Page 95 USB 2.0 Configuration The PCA-6005-B supports USB 2.0 device. From this chapter, you will find detail informaiton regarding Windows 2000 USB 2.0 driver setup procedure. Chapter 7...

  • Page 96: Chapter 7 Usb 2.0 Configuration

    Chapter 7 USB 2.0 Configuration 7.1 Introduction The PCA-6005-B is designed with SiS 962L as the I/O controller which supports both USB1.1 and USB 2.0 high-speed transmission. It still remains the compatibility with today's USB device. High-speed USB 2.0 provides data transfer up to 480Mb/s which is 40 times faster than USB 1.1.
  • Page 97 From Windows 2000, select Start and click on Setting. In the win- dow of Setting, click on icon System. Choose the option "Hardware", and then click on "Device Man- ager" Chapter 7...
  • Page 98 In Device Manager, choose "Universal Serial Bus (USB) Control- ler" and then double click. Choose the option "Driver" and then click on "Update Driver". PCA-6005-B User’s Manual...
  • Page 99 In Upgrade Device Driver Wizar, click on "Next". In Upgrade Device Wizard, choose "search for a suitable device for my driver" and then click on " Next". Chapter 7...
  • Page 100 Tick "Specify a location" and click "Next" In the following windows, please specify the location "D:\Drv_USB2\win2k" and then click on "OK". D:\Drv_USB2\win2k PCA-6005-B User’s Manual...
  • Page 101 Open "SiS USB Enhanced Host Controller Setup" window and click "Yes" to continue setup process.. Click "Accept" to continue setup. Click "Yes" to restart the computer. Chapter 7...
  • Page 102 After restarting the computer, repeat step 1 and 2 to open "Device Manager" window to check the status of "Universal Serial Bus (USB) Controller". PCA-6005-B User’s Manual...
  • Page 103 Programming the Watchdog Timer The PCA-6005-B is equipped with a watchdog timer that resets the CPU if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 104: Appendix A Programming The Watchdog

    Appendix A Programming the watchdog A.1 Programming the watchdog The PCA-6005-B's watchdog timer can be used to monitor system soft- ware operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it.

  • Page 105: Lock The Super I/O It8705F

    A.1.6 Lock the Super I/O IT8705F After setting the WDT and game port, lock it back to prevent unintended access. A.1.7 Resetting the Watchdog Timer Any read or write action from/to the game port will reset the watchdog timer. U n l o c k I T 8 7 0 5 S e l e c t W D T ( L o g i c a l N u m b e r = 5 ) E n a b l e a n d s e t t i m e t o...

  • Page 106: List Of Registers

    Game Port Base Address MSB Register (Index = 60h, Default = 02h) Description Read only with "0h" for Base Address [15:12] Game Port Base Address MSBRead/Write, mapped as Base Address [11:8] Game Port Base Address LSB Register (Index = 61h, Default = 01h) Description PCA-6005-B User’s Manual...
  • Page 107 Game Port Base Address LSBRead/Write, mapped as Base Address [7:0] Programming Examples ;-------------------------------------- ;Input :(AH) - register index (AL) - Value to write ;-------------------------------------- Set_8705_Reg proc near push dx, 2Eh al, ah dx, al 80h, al ; for I/O delay dx, al Set_8705_Reg endp ;--------------------------------------------...
  • Page 108 5 ; Select watchdog function call Select_Logic_Device ah, 30h ; Enable watchdog function al, 1 call Set_8705_Reg ah, 0FBh ; Set counter unit (second) l, 00011000b call Set_8705_Reg ah, 0FCh ; Use GP67 (pin 85) al, 37h PCA-6005-B User’s Manual...
  • Page 109 call et_8705_Reg ah, 0FDh ; Set time-out value al, 10 call Set_8705_Reg al, 6 ; Select game port function call Select_Logic_Device ah, 30h ; Enable game port function al, 1 call Set_8705_Reg ah, 60h ; Set game port address 201h al, 02h call Set_8705_Reg...
  • Page 110 1 call Set_8705_Reg ah, 60h ; Set game port address 201h al, 02h call Set_8705_Reg ah, 61h al, 01h call Set_8705_Reg call Lock_8705 ; Lock 8705 ; To reset the watchdog timer before the interval expires dx,201h PCA-6005-B User’s Manual...
  • Page 111 al,dx...
  • Page 112 PCA-6005-B User’s Manual...
  • Page 113 I/O Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • IDE Hard Drive Connector • Floppy Drive Connector • Parallel Port Connector • USB Connector • VGA Connector • Ethernet 10/100Base-T RJ-45 Connector • COM1/COM2 RS-232 Serial Port •...

  • Page 114: Appendix B Pin Assignments

    DATA 0 DATA 15 SIGNAL GND DISK DMA REQUEST IO WRITE IO READ IO CHANNEL READY HDACKO* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCA-6005-B User’s Manual...

  • Page 115: Floppy Drive Connector (Cn3)

    B.2 Floppy Drive Connector (CN3) Table B.2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active...

  • Page 116: Parallel Port Connector (Cn4)

    B.3 Parallel Port Connector (CN4) Table B.3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6005-B User’s Manual...

  • Page 117: Usb Connector (Cn6)

    B.4 USB Connector (CN6) Table B.4: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND...

  • Page 118: Vga Connector (Cn7)

    B.5 VGA Connector (CN7) Table B.5: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC PCA-6005-B User’s Manual...

  • Page 119: Keyboard And Mouse Connnector Cn11)

    B.6 Keyboard and Mouse Connnector CN11) Table B.6: Keyboard and mouse connector (CN11) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.7 External Keyboard Connector (CN12) Table B.7: External keyboard connector (CN12) Signal DATA...

  • Page 120: Ir Connector (Cn13)

    Table B.9: CPU fan power connector (CN14) Signal +12 V Detect B.10 Power LED (CN16) You can use an LED to indicate when the CPU card is on. Pin 1 of CN16 supplies the LED's power, and Pin 3 is the ground. PCA-6005-B User’s Manual...

  • Page 121: External Speaker Connector (Cn17)

    Table B.10: Power LED Function LED power (+5 V) Reserved B.11 External Speaker Connector (CN17) The CPU card has its own buzzer. You can also connect it to the external speaker on your computer chassis. Table B.11: External speaker (CN17) Function +5 VCC Internal buzzer...

  • Page 122: Reset Connector (Cn18)

    B.12 Reset Connector (CN18) Table B.12: Reset connector (CN18) Signal RESET B.13 HDD LED Connector (CN19) Table B.13: HDD LED connector (CN19) Signal LED0 (LED-) Vcc(LED+) PCA-6005-B User’s Manual...

  • Page 123: Atx Feature Connector (Cn20)

    B.14 ATX Feature Connector (CN20) Table B.14: ATX feature connector (CN20) Signal PS-ON VCCSB B.15 ATX Soft Power Switch (CN21) Table B.15: ATX soft power switch (CN21) Signal 5VSB PWR-BTN...

  • Page 124: External Sm Bus Connector (For Snmp-1000)

    Table B.16: External SM bus connector (for SNMP-1000) Signal SMB_DATA SMB_CLK B.17 AC-97 Audio Interface (CN43) Table B.17: System I/O ports 1 VCC 2 GND 3 SYNC 4 BITCLK 5 SDOUT 6 SDIN 7 SDIN2 8 -ACRST 9 +12V 10 GND PCA-6005-B User’s Manual...

  • Page 125: System I/O Ports

    B.18 System I/O Ports Table B.18: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 126: Dma Channel Assignments

    IRQ12 PS/2 mouse IRQ13 INT from co-processor IRQ14 Fixed disk controller IRQ15 Available IRQ3 Serial communication port 2 IRQ4 Serial communication port 1 IRQ5 Parallel port 2 IRQ6 Diskette controller (FDC) IRQ7 Parallel port 1 (print port) PCA-6005-B User’s Manual...

  • Page 127: 1St Mb Memory Map

    B.21 1st MB Memory Map Table B.21: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM CC000h - EFFFFh Unused C0000h - CBFFFh VGA BIOS B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh EGA/VGA graphics 00000h - 9FFFFh Base memory...
  • Page 128 PCA-6005-B User’s Manual...

Table of Contents
