Advantech AIMB-262 Startup Manual

AIMB-262 (Intel® LGA775 Core 2 Duo Mini ITX Moth-
erboard with DDR2/LAN/4COM/PCIe x16)
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. AIMB-262 Intel® LGA775 Core 2 Duo Mini ITX Moth-
erboard
2. SATA HDD cable x 2
3. SATA Power cable x 2
4. Serial port cable x 2
5. I/O port bracket x 1
6. Startup manual x 1
7. Driver CD x 1
Optional Cable
1. Parallel cable with bracket (P/N: 1700008809)
2. Dual port USB cable (27 cm) with bracket (P/N:
1700002204)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/readstep.html
(Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-262 series Rev. A1
Part No. 2006026210
Print in Taiwan
Specifications

Standard SBC functions

•
•
•
•
•
•
•
•
•
•
•
Graphic Interface
•
•
•

Ethernet Interface

•

Mechanical and Environmental

•
•
•
– Intel LGA775 Core 2 Due 1.8Mhz FSB800Mhz,2GB
DDR2
– +5 V @ 4 A, +3.3 V @ 1.02 A, +12 V @ 2.35 A, 5 V
0.26, -12 V@ 0.12 A Measure the maximum current value
which system under maximum load (CPU: Top speed, RAM
& Graphic: Full loading)
•
•
1st Edition,
August 2008
CPU: Intel® LGA775 Core 2 Due,Pentium® due-core,
Pentium® 4, Celeron® D
FSB: 533/ 800 MHz
BIOS: Award 16 Mbit SPI
Chipset: Intel 945GC with ICH7
System Memory: Up to 2 GB; 200-pin SODIMM x 2,
Supports dual channel DDR 533/667 SDRAM
SATA: Two onboard serial ATA connectors with a data
transmission rate of up to 300 MB/s
Serial ports: Four serial ports: Three of RS-232; One of
RS-232/422/485
Parallel port: One parallel port, supports SPP/EPP/ECP
mode (with pin header)
Keyboard/mouse connector: Supports one standard
PS/2 keyboard, one standard PS/2 mouse
Watchdog timer: 255 level timer intervals
USB 2.0: Supports up to six USB 2.0 ports, four external
ports and two onboard pin headers
Controller: Chipset integrated VGA controller
Display memory: Dynamically shared system memory
up to 224 MB
CRT: Up to 2048x1536 resolution, 400MHz RAMDAC
Single 10/100/1000Base-T GbE LAN Realtek RTL8111C
Dimensions (L x W): 170 x 170 mm
Power supply voltage: +5 V, +12 V, +3,3 V, +5 V
-12 V
Power requirements:
Operating temperature: 0 ~ 60° C (depending on CPU)
Weight: 0.365 kg (weight of board)
