Advantech AIMB-224 Startup Manual

AIMB-224 Mobile AMD R-series Qual Core/Dual Core
FS1r2 socket Mini-ITX Motherboard with VGA/LVDS/
Display Port, 6 COMs and Dual LAN
Startup Manual

Packing List

Before you begin installing your single board, please make
sure that the following materials have been shipped:
1. 1 x AIMB-224 Mini ITX Motherboard
2. 1 x CD-ROM or DVD-ROM contains the following:
- User's Manual
- Drivers
3. 1 x Serial port cable
4. 2 x SATA HDD Data cable
5. 2 x SATA Power cable
6. 1 x I/O shield
7. 1 x CPU cooler
8. 1 x Startup manual
9. 1 x Warranty card
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the AIMB-224 series Rev. A1
Part No. 2006022410

Processor System

• CPU: Support AMD R-series Quald Core 2.3 GHz/Quad
• Max. Speed: 2.3 GHz (Quald Core)
• L2 Cache: 1 MB/per core
• Chipset: A75M
• BIOS: 16 Mbit SPI

Expansion Slot

• Mini-PCIe: 2 (1 Full-size colay mSATA/ 1 Half-size)
• PCIe: PCIe x 8 (PCIe gen 3)

Memory

• Technology: Dual channels DDR3 1333/1600 MHz
• Max. Capacity: 16 GB
• Socket: 2 x 204-pin SODIMM

Graphic Interface

• Controller: AMD Radeon™ GPUs (RadeonTM HD 7xxx),
• VGA: Supports up to 4096 x 2400 @ 60 Hz
• LVDS:Supports 24-bit dual channel and 1920 x 1200
• Display Port: Two dual model display port, max resolu-
• Triple Display: Supports Triple display of CRT/LVDS/DP
• Dual Display: Supports dual display of any two display

Ethernet Interface

• Interface: 10/100/1000 Mbps
• Controller: GbE LAN1: RTL8111E;
• Connector: RJ-45 x 2

SATA Interface

• Max Data Transfer Rate: 600 MB/s
• Channel: 3

Rear I/O

• VGA: 1
• DP: 2
• Ethernet: 2
• USB: 4 (2 USB 3.0 / 2 USB 2.0)
• Audio: 3 (Mic-in, Line-out, Line-in)
• Serial: 1 (RS-232)
1st Edition
• PS/2: 1
October 2011
• DCIN Jack: 1

Specifications

Core 1.9 GHz/ Dual Core 2.7 GHz / Dual Core 2.5 GHz
FS1r2 socket type processor
support DirectX 11, UVD3
tion: 1920 x 1200@60 Hz
device (CRT, LVDS, DP)
GbE LAN2: RTL8111E
AIMB-224 Startup Manual 1
