Intuicom RTK Bridge-X Installation Manual page 5

• Configure the pinout on the Deutsch connector on the RTK Bridge–X to FMX
data/power cable to match the appropriate pin-out. See Pin-out Diagram 1
Deutsch
3
6
1
4
4
Deutsch connector
(DTM06-12S)
pinout
• Using the Intuicom RTK Bridge–X to FMX data/power cable (XRTKCAB-DD6),
connect the RTK Bridge–X data port to the D Port on the FMX.
• Apply power and connect to the FMX
• Using the touchscreen on the FMX, enter the configuration screen by selecting the
"tools" button.
Version 1.0
Pin-out Diagram 1
Cable Color
Red
Receive (from RTK Bridge-X to
Green
Xmit (to RTK Bridge-X from
White
Black
Brown
Section 2: Installation Instructions
Signal
Power
remote device)
remote device)
Power Ground
Signal Ground
1 2 3 4 5 6
12 11 10 9 8 7
4
FMX D-Port
9
3
4
8
5
Intuicom, Inc.
