Fiber LC Interface) on the front plate.
4. Power up the system
5. Configure your system using the network driver appropriate to your operating
system.

2.4 Cable connecting info

2.4.1 Fiber cabling:
Insert the fiber optic cable into the LC type connector so that the self-locking tab
clicks into position. Connect the opposite end to a 1000Base-SX switch. Ensure that
the TX port of the adapter is connected to the RX port of the switch, and RX to the
TX, check the red light from RX port. The maximum length is typical:
Table 2-1: Gigabit Ethernet physical media support
Fiber Core Diameter
62.5/125 um
62.5/125 um
50.0/125 um
50.0/125 um
8.0/125 um
* (850 nm Laser for multimode-SX, 1310nm laser for single-mode-LX)
2.4.2 RJ-45 cabling:
Insert the fiber optic cable into the RJ-45 connector so that the self-locking tab
clicks into position. The maximum cable length is typically 100 meters.

2.5 Front Panel LED Indicators

There are two diagnostic LEDs on the front panel. These LEDs show the operating
status of the MIC-3665.
ON
LINK/ The link between the hub/switch and
ACTIVITY adapter is active
LED blinks during data transmission
SPEED* RED for 1000Base-T
Green for 100Base-TX
* MIC-3665 Fiber has no "speed" LEDs (only in 1000Base-X)
Type Fiber Bandwidth Mhz* km
multi-mode* 160 Mhz * km
multi-mode 200 Mhz * km
multi-mode 400 Mhz * km
multi-mode 500 Mhz * km
single-mode 500 Mhz * km
Table 2-2: LED Indicator definitions
Distance
2 to 220 m
2 to 275 m
2 to 500 m
2 to 550 m
5-10 km
OFF
No link between the hub/switch and
adapter
Operating in 10Base-T
