Quick Start Guide
ACX6160 Universal Metro Router
IN THIS GUIDE

About This Quick Start Guide

This Quick Start Guide contains information you need to install and connect the Juniper Networks ACX6160 Universal
Metro Router. For complete installation instructions, see the ACX6160 Universal Metro Router Hardware Guide at
https://www.juniper.net/documentation/.
WARNING:
on page
Universal Metro Router Hardware Guide at
The Juniper Networks ACX6160 Universal Metro Router is a standalone optical disaggregated transponder that has 12
network ports, of which 8 are (QSFP28) client ports, and 4 are (CFP2-DCO) line ports. It has removable DC power supplies
and cooling fans.
This Quick Start Guide contains a summary of safety warnings in
12. For a complete list of warnings for the ACX6160, including translations, see the ACX6160
https://www.juniper.net/documentation/.
"Safety Warnings Summary"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACX6160 and is the answer not in the manual?

Questions and answers

Related Manuals for Juniper ACX6160

Summary of Contents for Juniper ACX6160

  • Page 1: Table Of Contents

    Power Cable Warning (Japanese) | 13 About This Quick Start Guide This Quick Start Guide contains information you need to install and connect the Juniper Networks ACX6160 Universal Metro Router. For complete installation instructions, see the ACX6160 Universal Metro Router Hardware Guide at https://www.juniper.net/documentation/.

  • Page 2: Step 1: Prepare Your Site For The Acx6160

    ESD point on the chassis. 2. Decide whether the field-replaceable unit (FRU) end or the port end of the ACX6160 must be placed at the front of the rack. Position the ACX6160 in such a manner that the AIR OUT labels on components are next to the hot aisle.
  • Page 3 Figure 2: Attaching the ACX6160 (with Mounting Rails to the Rack) 8. Continue to support the ACX6160 while sliding the rear-mounting blades into the channel of the mounting-rails on the sides of the chassis and securing the blades to the rack. Use four mounting screws (and cage nuts and washers if your rack requires them) to attach the blade to the rack.
  • Page 4 Figure 3: Sliding Mounting Blades into the Mounting Rail 9. Ensure that the ACX6160 chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack.

  • Page 5: Step 4: Connect The Grounding Cable

    Ensure that you have the following parts and tools available: Grounding cable for your ACX6160 device—The grounding cable must be 14 AWG (2 mm²), minimum 90° C wire, or as permitted by the local code. We have grounding points on either side or on one side of the chassis. These can be seen through the gaps in the mounting rails/blades.

  • Page 6: Step 5: Connect To The Management Console

    Step 5: Connect to the Management Console The ACX6160 has a console port with an RJ-45 connector. Use the console port to connect the device directly to a management console, such as a laptop, or to a console server.

  • Page 7: Step 6: Power On The Acx6160

    Connecting DC Power to the ACX6160 The ACX6160 is shipped from the factory with two power supplies. Each power supply is a hot-removable and hot-insertable field-replaceable unit (FRU) when the second power supply is installed and running. You can install replacement power supplies in the two slots next to the fan modules without powering off the device or disrupting the routing functions.
  • Page 8 For instructions on connecting earth ground, see Connecting the ACX6160 Grounding Cable. Install the power supply in the chassis following the instructions in Installing a Power Supply in an ACX6160 see the ACX6160 Universal Metro Router Hardware Guide.
  • Page 9 Figure 8 Figure 9). The ACX6160 is designed to operate with a DC power supply that has a single, nonredundant, feed input. For source redundancy, two DC power supplies must be installed; connect source (A) to one power supply and connect source (B) to the second power supply.
  • Page 10 The V+ terminals are shunted internally together, as are the V- terminals. Do not connect the terminals to different sources. Figure 9: Securing Ring Lugs to the Terminals on the ACX6160 DC Power Supply 8. Replace the terminal block cover.

  • Page 11: Step 7: Perform The Initial Configuration

    By default, the ACX6160 is set up for dynamic IP address assignment. The following process takes place: When the ACX6160 powers on, it requests an IP address from the DHCP server in your management network. This assigned IPv4 or IPv6 address is temporary and allows the Open ROADM controller to establish initial contact for commissioning the ACX6160.

  • Page 12: Safety Warnings Summary

    ACX6160 features. Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the ACX6160 Universal Metro Router Hardware Guide at https://www.juniper.net/documentation/. WARNING: Failure to observe these safety warnings can result in personal injury or death.

  • Page 13: Power Cable Warning (Japanese)

    If the rack or cabinet has stabilizing devices, install them in the rack before mounting or servicing the ACX6160 in the rack or cabinet. Before installing or after removing an electrical component, always place it component-side up on a flat antistatic mat or in an electrostatic bag.
