Quick Start Guide
ACX6360
IN THIS GUIDE
ACX6360 Quick Start | 1
Part 1: Mount the Device | 2
Part 2: Connect Power to an AC-Powered Router | 3
Part 3: Perform the Initial Configuration | 4
Safety Warnings Summary | 6
ACX6360 Quick Start
See the complete ACX Series documentation at https://www.juniper.net/documentation/. To install and configure a
Juniper Networks ACX6360 Router, you need:
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of front mounting rails (provided)
One pair of rear mounting blades (provided)
Twelve screws to secure the mounting rails and mounting blades to the chassis (provided)
Eight screws to secure the chassis and mounting blades to the rack (not provided)
Screwdriver appropriate for your rack mounting screws (not provided)
Two power cords with plugs appropriate for your geographical location (provided)
RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided)
Advertisement
Related Manuals for Juniper ACX6360
Summary of Contents for Juniper ACX6360
- Page 1 Part 3: Perform the Initial Configuration | 4 Safety Warnings Summary | 6 ACX6360 Quick Start See the complete ACX Series documentation at https://www.juniper.net/documentation/. To install and configure a Juniper Networks ACX6360 Router, you need: Electrostatic discharge (ESD) grounding strap (not provided)
-
Page 2: Part 1: Mount The Device
Management host, such as a PC laptop, with a serial port (not provided) (Optional) Grounding cable kit with bracket, lug, and three screws. To install the grounding cable, see the ACX6360 documentation at https://www.juniper.net/documentation/product/en_US/acx6360 Part 1: Mount the Device The ACX6360 can be mounted in a 19-inch four-post rack. -
Page 3: Part 2: Connect Power To An Ac-Powered Router
11. Attach a grounding cable to earth ground and then attach it to the chassis grounding points (on the side of the chassis). Part 2: Connect Power to an AC-Powered Router For instructions on connecting DC power, see the installation instructions in the ACX6360 documentation at https://www.juniper.net/documentation/product/en_US/acx6360. -
Page 4: Part 3: Perform The Initial Configuration
By default, Zero touch provisioning (ZTP) starts automatically. Zero touch provisioning (ZTP) allows you to provision new Juniper Networks devices in your network automatically, with minimal manual intervention. You can use either management ports or network ports on your switch to connect to the network. When you physically connect a device to the network and boot it with a default factory configuration, the device upgrades (or downgrades) the Junos OS release and autoinstalls a configuration file from the network. - Page 5 NOTE: The management port em0 is on the port panel, and the management port em2 is on the FRU end of the ACX6360 router. 9. (Optional) Configure the static routes to remote prefixes with access to the management port. [edit] root@# set routing-options static route remote-prefix next-hop destination-IP retain no-readvertise 10.
-
Page 6: Safety Warnings Summary
[edit] root@# commit Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the ACX6360 router documentation at https://www.juniper.net/documentation/product/en_US/acx6360. WARNING: Failure to observe these safety warnings can result in personal injury or death. - Page 7 For technical support, see: http://www.juniper.net/support/requesting-support.html Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
