Powerfix Profi 314158 Operation And Safety Notes page 13

12. Care should be taken that the lashing is not damaged by sharp
edges of the load on which it is used.
A visual inspection before and after each use is recommended.
13. Only legibly marked and labelled web lashings shall be used.
14. Lashing straps must not be overloaded: The maximum hand force
25 daN for model HG04648; 50 daN for model HG04646 and
HG04647 (1 daN ≈ 1 kg) may be applied. Mechanical aids such
as bars or levers etc. may not be used unless they are part of the
tensioning device (HG04646 / HG04647 / HG04648).
15. Lashings shall never be used when knotted.
16. Damage to labels shall be prevented by keeping them away from
sharp edges of the load and, if possible, from the load.
17. Webbing must be protected against friction, abrasion and damage
from loads with sharp edges by using protective sleeves and / or
corner protectors.
˜ Use
Lashing down (HG04646 / HG04647 / HG04648):
With lashing straps stretched over it, the load is pressed down onto the
loading area (Fig. I).
Diagonal lashing (HG04648):
The load is secured by 4 lashing straps and directly connected to the
vehicle (Fig. II).
GB 13
