AS241F
Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution:
Input Signal
VNA:
Mini D-Sub 15-pin: Analog RNB
DisplayPort:
DisplayPort Connector: Digital RNB
HDMI:
HDMI Connector: Digital RNB, Digital YUV
Display Colors
Synchronization Range
Viewing Angle
Response Time
Active Display Area
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Headphone Output: STEREO Mini Jack:
Speakers
Practical Audio Output: 1.0 W+ 1.0 W
Power Supply
Current Rating
Dimensions
Stand adjustable range
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
OTEE:
Technical specifications are subject to change without notice.
AccuSync AS241F
Diagonal:
60.47 cm/23.8 inches
60.47 cm/23.8 inches
1920 x 1080 60 Hz
Sync
16777216
Horizontal:
31.5 kHz to 83.0 kHz
Vertical:
50 Hz to 75 Hz
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
6 ms (Nray to Nray Typ.)
Horiz.:
527.0 mm/20.7 inches
Vert.:
296.5 mm/11.7 inches
Analog Audio
Digital Audio
Digital Audio
AC 100-240 V, 50/60 Hz
0.60 - 0.35 A
538.1 mm (W) x 408.0 (H) x 182.0 mm (D)
21.2 inches (W) x 16.1 inches (H) x 7.2 inches (D)
Tilt: UP 20° Down 5°
3.5 kg (7.7 lbs) (with monitor stand)/3.1 kg (6.8 lbs) (without monitor stand)
5°C to 35°C/41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 16,404 Feet/0 to 5,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
English−25
otes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.275 mm dot pitch; 250 cd/m
luminance; 1000:1 contrast ratio (typical).
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Up to 1920 x 1080 60 Hz, DisplayPort V1.1a
(HDCP 1.3)
Up to 1920 x 1080 60 Hz, HDMI (HDCP 1.4)
Depends on display card used.
Automatically
Automatically
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
white
2
