Mount the Flexible Arm
Using four screws that meet the specifications listed below, attach the arm to the monitor.
CAUTIOE: •
The monitor should only be used with an approved arm (e.g. TUEV NS mark).
•
Tighten all screws (recommended fasten torque: 98 - 137 N•cm).
•
Attaching the flexible arm should be done by two or more people if the monitor cannot be placed face down
on a flat surface for installation.
100 mm
100 mm
Figure F.1
English−16
Screw (M4)
Washer
Mounting
Bracket
Unit
Thickness of
bracket and
washer
8 - 10 mm
