Table of Contents
Picture Menu
BRINHTNESS
ECO MODE
OFF
1 (10% POWER SAVINNS)
2 (30% POWER SAVINNS)
CONTRAST
COLOR
RED
NREEN
BLUE
SHARPNESS
H POSITION (Analog input only)
V POSITION (Analog input only)
CLOCK (Analog input only)
PHASE (Analog input only)
AUTO CONTRAST
(Analog input only)
AUTO ADJUST
(Analog input only)
PICTURE RESET
*: L/B is an abbreviation of Low Blue Light.
Sound
Sound Menu
SOUND INPUT
MUTE
VOLUME
Adjusts the overall image and background screen brightness.
Decreases the amount of power consumption by reducing the brightness level.
Sets brightness variable from 0% to 100%.
Sets the brightness variable range from 0% to 80%.
Sets the brightness variable range from 0% to 40%.
Adjusts the image brightness in relation to the background.
OTEE:
This function is disabled when [COLOR] is set to [L/B].
Select the desired color setting from six color presets (9300 / 7500 / sRNB / USER / NATIVE / L/B*).
OTEE:
When [L/B] is selected in [COLOR] control, [CONTRAST] is disabled.
Increases or decreases [RED]. The change will appear on screen.
Increases or decreases [NREEN]. The change will appear on screen.
Increases or decreases [BLUE]. The change will appear on screen.
Adjusts the crispness of the image.
Controls the horizontal position of the image within the display area of the LCD.
Controls the vertical position of the image within the display area of the LCD.
Press UP button to expand the width of the image on the right of the screen.
Press DOW button to narrow the width of the image on the left of the screen.
Adjusts the visual "noise" in the image.
Adjusts the image displayed for non-standard video inputs.
[H POSITION], [V POSITION], [CLOCK] and [PHASE] are adjusted automatically when new timing is
detected.
Resets all PICTURE settings back to default settings.
Selects the sound input source.
Mutes the speaker output.
Controls the volume of the speakers or headphones.
English−27
