CHAPTER 1 Introduction
1

Introduction

This document provides a hardware description of the Mediant 500 E-SBC (hereafter referred to as
device) and step-by-step procedures for mounting and cabling the device.
The device supports the following interfaces:
■ Four Gigabit Ethernet (10/100/1000Base-T) LAN ports
■ Single E1/T1 port interface over a single copper wire pair (PRI interface is a separate-orderable
item)
■ Two USB ports for optional, USB storage services
■ Serial console port (RJ-45) for device management
●
●
Serial Hardware configurations may change without notice. Currently available
hardware configurations are listed in AudioCodes Price Book. For further enquiries,
please contact your AudioCodes sales representative.
For information on configuring the device, refer to the device's User's Manual.
