CMC III Analoger Luftstromsensor CMC III Analogue Air Flow Sensor Détecteur de débit d'air analogique CMC III 7030.140 Installationsanleitung und Kurz-Bedienungsanleitung Installation Guide and Short User's Guide Notice d'installation et d'utilisation succincte...
Page 2
Abb./Fig./Fig. 2: Montage / Assembly / Montage Abb./Fig./Fig. 3: Anzeigeelemente, Stecker und Anschlüsse / Display elements, plugs and connectors / Organes de signalisation, fiches et raccordements Rittal CMC III Analoger Luftstromssensor / Analogue Air Flow Sensor / Détecteur de débit d’air analogique...
Informationen zur Montage, Installation und Funktion des CMC III Analogen Luft- stromsensors (nachfolgend Luftstromsensor genannt). Mitgeltende Unterlagen Montage-, Installations- und Bedienungsanleitung CMC III Analoger Luftstromsensor. Sie ist unter www.rittal.de verfügbar und enthält die vollständigen anwendungsrelevanten Informationen und technischen Daten zum Luftstromsensor in Hinblick auf: – Weitere Montagemöglichkeiten – Funktionen –...
Drücken Sie die „C“-Taste an der CMC III PU (ein erster Signalton ertönt) und halten Sie sie für ca. 3 Sekunden gedrückt, bis ein zweiter Signalton ertönt. Anzeige der Statusänderung an den CAN-Bus LEDs: – Dauerlicht grüne LEDs: Status CAN-Bus „OK“. – Dauerlicht rote LEDs: Status CAN-Bus fehlerhaft. Rittal CMC III Analoger Luftstromssensor...
Page 5
– SetPtLowAlarm: unterer Alarmgrenzwert [%] – Hysteresis: Verzögerung der Statusmeldung [%] – Status: Aktueller Status des Luftstromsensors unter Berücksichtigung der Hysterese Eventuell notwendige Softwareupdates: siehe www.rittal.de oder Anfrage bei Rittal Service (vgl. Abschnitt 6). Service Zu technischen Fragen wenden Sie sich bitte an: Tel.: +49(0)2772 505-9052...
Associated documents CMC III Analogue Air Flow Sensor assembly, installation and user's guide. It is available at www.rittal.com and contains the complete application-relevant information and techni- cal data for the air flow sensor with regard to: – Further assembly possibilities –...
3 seconds until a second audio signal is issued. Display of the status change on the CAN bus LEDs: – Green LEDs light continuously: CAN bus status "OK". – Red LEDs light continuously: CAN bus status faulty. Rittal CMC III Analogue Air Flow Sensor...
Page 8
– SetPtLowAlarm: Lower alarm limit value [%] – Hysteresis: Status message delay [%] – Status: Current status of the air flow sensor taking account of the hysteresis To determine whether any software updates are required: see www.rittal.com or contact Rittal Service (see section 6). Service For technical questions, please contact: Tel.: +49(0)2772 505-9052...
Notice de montage, d'installation et d'utilisation du détecteur de débit d’air CMC III. Elle est disponible sous www.rittal.com et contient les informations complètes relatives à la mise en œuvre et les caractéristiques techniques du détecteur de débit d’air dans les domaines suivants : –...
– La LED multiple du détecteur de débit d’air clignote en bleu de manière continue. Actionner la touche «C» de l'UC CMC III (un premier signal sonore retentit) et la maintenir actionnée pendant env. 3 secondes jusqu'à ce qu'un deuxième signal sonore retentisse. Détecteur de débit d’air analogique CMC III Rittal...
Page 11
– Hysteresis : temporisation du message d'état [%] – Status : état actuel du détecteur de débit d’air du point de vue de l'hystérésis Si des mises à jour de logiciel sont éventuellement nécessaires : voir www.rittal.com ou sur demande au service Rittal (voir paragraphe 6).
Page 12
Pour des questions techniques, veuillez vous adresser à : Tél. : +49(0)2772 505-9052 E-mail : info@rittal.de Site Internet : www.rittal.com Pour des réclamations ou un service, veuillez vous adresser à : Tél. : +49(0)2772 505-1855 E-mail : service@rittal.de Détecteur de débit d’air analogique CMC III Rittal...
Page 14
