11. Measure output voltage on terminals marked [COM, 24V, 28V] on WayPoint30AU or WayPoint30ADU
(Fig. 2, pg. 4) or [1-4] or [1-8 COM] on WayPoint30A4U, WayPoint30A4DU, WayPoint30A8U and
WayPoint30A8DU before connecting devices (Fig. 3, pg. 5, Fig. 4, pg. 6).
This helps avoiding potential damage.
12. Set illuminated master power disconnect circuit breaker to the [OFF] position (Figs. 2-4, pgs. 4-6).
13. Connecting devices to WayPoint30AU or WayPoint30ADU:
For 24VAC output connect devices to terminals marked [COM, 24V] (Fig. 2, pg. 4).
For 28VAC output connect devices to terminals marked [COM, 28V] (Fig. 2, pg. 4).
Connecting devices to WayPoint30A4U or WayPoint30A4DU:
Connect device to terminals marked [1-4] and [COM] (Fig. 3, pg. 5).
Connecting devices to WayPoint30A8U or WayPoint30A8DU:
Connect device to terminals marked [1-8] and [COM] (Fig. 4, pg. 6).
14. Set illuminated master power disconnect circuit breaker to the [RESET/ON] position (Figs. 2-4, pgs. 4-6).
15. LEDs will illuminate indicating each output is powered (Figs. 2-4, pgs. 4-6).
16. Upon completion of wiring secure enclosure door with latches and optional lock.
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: When installing in a non-restricted service area use lock or other fastened means on door
latches. This installation should be made by qualified service personnel and should conform to all local
codes and in accordance with the National Electrical Code.
ON
Normal operating condition.
To reset a tripped PTC turn the power off for 1 minute and then turn it back on.
Parameter
Input power
requirements
Indicators
Environmental Conditions
Regulatory Compliance
For fuse protected models:
Replace blade type fuses with ratings from 3A up to 10A.
WayPoint30AU and WayPoint30A4U incorporates 10A fuses. WayPoint30A8U incorporates 5A fuses.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may
be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WayPoint30A Series
LED Identification Chart:
OFF
No AC output. Blown fuse or tripped PTC, illuminated master power disconnect
circuit breaker is tripped or OFF, AC failure.
Technical Specifications:
Description
115VAC, 60Hz, 3A or 230VAC, 50Hz, 1.5A.
Individual power output LED indicators.
Illuminated master power switch.
Operating Ambient Temperature:
For 24VAC @ 12.5A output: - 40°C to 60°C (- 40°F to 140ºF).
For 28VAC @ 10.0A output: - 40°C to 70°C (- 40°F to 158ºF).
Relative Humidity:
Storage Temperature:
Operating Altitude:
UL/cUL Listed for
CE
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
85%, +/- 5%
- 40ºC to 75ºC (- 40ºF to 167ºF).
- 304.8 to 2,000m.
Information Technology Equipment (UL 60950-1)
Equipment to be Installed Outdoors (UL 60950-22).
European Conformity.
