G2 Series Installation Instructions
Fit Doors 35mm(1-3/8 ) to 50mm(2 ) Thick
INSIDE
ROSE
INSIDE
LEVER
DOOR HANDING
INSIDE
RIGHT HAND
OUTSIDE
INSIDE
RIGHT
REVERSE
BEVEL
OUTSIDE
IN THE BOX DOOR HANDS DETERMINED FROM OUTSIDE
DISASSEMBLE INSIDE LEVER AND ROSE
PUSH PIN
HOLE
INSIDE
LEVER
1A:
Inser t push pin into hole
in inside lever to depress catch.
"
"
Backset 70 mm (2-3/4 )
LOCK BODY
MOUNTING
SCREW
SLEEVE
For 25mm(1
Hole
INSIDE
SPRING CAGE
LEFT HAND
LEFT
REVERSE
BEVEL
CATCH
INSIDE
LEVER
1B:
Remove the inside
lever from spindle.
"
POST
OUTSIDE
TRIM
")
LATCH
COMBINATION
SCREW
STRIKE
STRIKE BOX
INSIDE
SPRING CAGE
INSIDE
ROSE
TURN
AND
PULL
1C:
Remove inside rose
by turning and pulling off.
ADAPTOR
OUTSIDE
LEVER
KEY
CYLINDER
ASSEMBLY
PUSH PIN
New Door Preparation
A:
Fold template on edge of
"
door mark site 70mm(2-3/4
)
of holes.
B:
"
Drill a
54mm(2-1/8
)
hole
through door (from both sides
to avoid damaging door).
C:
"
Drill a 25mm (1 ) hole in
door edge.
D:
Cut out a 58x29x4mm
"
"
"
(2-9/32
x1-1/8
x5/32
) base.
CENTER LINE
LOCK BODY
MOUNTING
SCREW
Unclench by
screwdriver
1D:
Unscrew two mounting
screws in lock body by screwdriver.
NOTE: For doors thinner
")
than 35 mm (1-3/8
fit adaptors supplied
under inside spring
cage and/or outside trim.
BASE
54
29
25
58
4
70
LE70644A
