- Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
- Page 2 ACB-ULTRA.LPCI User Manual Part Numbers 5104 5104S www.sealevel.com PO Box 830 Liberty, SC 29657 864.843.4343 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 3: Table Of Contents
Table of Contents Introduction ........................... 1 ACB-ULTRA.LPCI ........................1 Other Sealevel Sync Products ..................... 1 Before You Get Started ........................ 2 What’s Included .......................... 2 Optional Items ..........................2 Software Installation ........................3 Windows 2000/XP Installation ....................3 Physical Installation ........................4 Technical Description ........................ - Page 4 Federal Communications Commission Statement ..............22 EMC Directive Statement ..................... 22 Warranty ............................. 23 Trademarks ........................... 24 ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. SL9076 Revision 8/2017 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 5: Introduction
PCI slot. The ACB-ULTRA.LPCI is a ‘Universal Bus’ adapter, allowing for use in either +5 or +3.3V PCI slots and provides compliance with the PCISIG PCI Bus Specification Revision 2.2/2.3, which requires ATX power support for both 5V and 3.3V. Other Sealevel Sync Products • PC/104 ACB-104 (P/N 3512) - Z85230 RS-232/422/485/530/530a/V.35... -
Page 6: Before You Get Started
Optional Items Depending upon your application, you are likely to find one or more of the following items useful for interfacing the ACB-ULTRA.LPCI to real-world signals. All items can be purchased from our website (http://www.sealevel.com) or by calling 864-843- 4343. •... -
Page 7: Software Installation
1. Start Windows. 2. Insert the Sealevel Systems CD in to your CD drive. 3. If ‘Auto-Start’ is enabled for this drive the software will automatically launch. Otherwise, point your browser to the ‘Index.htm’ on the root directory of the CD 4. -
Page 8: Physical Installation
7. Connect the power cord and power up the machine. The ACB-ULTRA.LPCI is now ready for use. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 4 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 9: Technical Description
High Memory options: 16 pages of 16K memory blocks totaling 256K or one linear block of 256K memory ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 5 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 10: Control And Status Registers Defined
RESTAT Reset status: 1 = On-board reset inactive; 0 = On-board reset active. Remote loopback Local loopback ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 6 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 11 1=256K linear block in high memory only, 0=16X16K pages in low or high memory, (0 on power-up) ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 7 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 12: Interface Selection
Address SA6 S/D (serial/DMA) Address SA7 DMA channel registers Base + 0-127 Serial controller base + 128-255 ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 8 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 13: I/O Signal Derivation
The ACB-ULTRA.LPCI input/output signals are directly generated via the Zilog 16C32 IUSC. The following table defines these signals, their origin pin and signal name following the conventions set by the 16C32 user’s manual. If using a Sealevel Systems, Inc. supplied driver, this is for informational use only. -
Page 14: Rs-232 Signals
Output Test Mode Input *When in External Sync mode, the external sync signal is fed into DCD. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 10 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 15: Rs-485 Or Rs-485T
1K Ω resistor from RX- to GND, and add 820 Ω resistor from RX+ to +5V DTR (depending on state of DTR in application – do not toggle DTR). ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 11 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 16: Rs-530 (Rs-422)
Transmit Signal Element Timing – Output *When in External Sync mode, the external sync signal is fed into DCD. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 12 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 17: Rs-530A
DTRA DTR– Data Terminal Ready Negative Output Remote Loopback Output TSETA TSET– Transmit Signal Element Timing – Output ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 13 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 18: V.35 Signals
When in External Sync mode, the external sync signal is fed into DCD. Terminating these pins, if not used, will help insure you get the best performance from your adapter. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 14 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 19: Specifications
Range Non-Condensing Non-Condensing Manufacturing All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. Power Consumption Supply line +3.3VDC... -
Page 20: Appendix A - Troubleshooting
IRQ (if any) should be identified. 5. Configure your Sealevel Systems adapter so that there is no conflict with currently installed adapters. No two adapters can occupy the same I/O address. -
Page 21: Appendix B - How To Get Assistance
FTP site that can be accessed from our home page. Manuals and software can also be downloaded from the product page for your device. Sealevel Systems provides an FAQ section on our website. Please refer to this to answer many common questions. This section can be found at http://www.sealevel.com/faq.asp... -
Page 22: Appendix C - Electrical Interface
+12 volts (usually +3 to +10 volts) represents a binary 0 (space) and -12 volts (- 3 to -10 volts) denotes a binary 1 (mark). The RS-232 and the EIA/TIA-574 specification defines two type of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface. RS-422 The RS-422 specification defines the electrical characteristics of balanced voltage digital interface circuits. -
Page 23: Rs-485
RS-530A some of these signals are single ended. The RS- 530 specification defines two types of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface. V.35 V.35 is a standard defined by ITU (formerly CCITT) that specifies an electrical,... - Page 24 Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 20 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 25: Appendix D - Silk Screen - 5104 Pcb
Appendix D – Silk Screen – 5104 PCB 2.536" 4.721" ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 21 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 26: Appendix E - Compliance Notices
FCC/EMC directives. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 22 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 27: Warranty
Sealevel Systems assumes no liability for any damages, lost profits, lost savings or any other incidental or consequential damage resulting from the use, misuse of, or inability to use this product. Sealevel Systems will not be liable for any claim made by any other related party. -
Page 28: Trademarks
Trademarks Sealevel Systems, Incorporated acknowledges that all trademarks referenced in this manual are the service mark, trademark, or registered trademark of the respective company. ACB-ULTRA.LPCI User Manual © Sealevel Systems, Inc. - 24 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 29 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
