CHANNEL POWER

The channel power measurement displays the power of
the channel found by SCAN BAND or a channel selected
by the operator. Use this measurement to identify an
AP or NIC that is not transmitting at the correct power
level.
If you know exactly which channel you want, choose
SELECT CHANNEL in the sub-menu.
Access the text measurement display option anytime
by pressing the LEFT ARROW button. Press the same
button again to return to the graphical measurement
display.

POWER PROFILE

Use the POWER PROFILE measurement to view the
shape of the frequency vs. power characteristic of the
AP or NIC under test.
As with the CHANNEL POWER measurement, this
measurement analyzes the channel found by BAND
SCAN or a channel selected by the operator. This
measurement is used to identify an AP or NIC with a
frequency response (filter) problem.
Access the text measurement display option anytime
by pressing the LEFT ARROW button. Press the same
button again to return to the graphical measurement
display.
