playback. The name of the file can also be typed into the File Name edit box. Don't forget to add
the extension .cpd when entering the playback file name in this way.
Figure 29 display shows how the File Status box and switches appear during a replay. Note that the
USB LED is off indicating that the data displayed is not real time but recorded. Note also that the
replay has been paused in figure 20. To resume, click the PAUSE switch again.
Figure 29
SPECIAL REPLAY SWITCHES
The FAST/SLOW switch is used to modify the speed of playback.
Click the REWIND switch to run the current playback file in reverse from the current position.
Note the progress bar and the Wi-Fi Power Analyzer below the graph also change direction during
REWIND.
Click the PLAY or STOP switch to stop the current replay. The application will reconnect to the USB
and real time data displayed as before.
If a Wi-Fi Power Analyzer is NOT connected to the PC, the application can still be used to play
recorded data files.
TROUBLE SHOOTING
Page 25
