Bicker Elektronik UPSI-IP-1 Series User Manual page 54

21.2 Command Index "Sensors" 0x02
GetCPUTemperature() 0x00
This read function returns the cpu temperature.
Cmd
0x00 GetCPUTemperature()
Transfer packet:
GetOutputCurrent() 0x01
This read function returns the output current.
Cmd
0x01 GetOutputCurrent ()
Transfer packet:
GetInputVoltage() 0x02 (not connected at moment)
This read function returns the input voltage.
Cmd
0x02 GetInputVoltage ()
Transfer packet:
21.3 Command Index "Charge Controller" 0x03
GetEnergyStorageVoltage() 0x20
This read-word function returns the measured voltage of the capacitor 1.
Cmd
0x20 GetEnergyStorageVoltage ()
Transfer packet:
54
Name Access
0x01 0x03 0x02 0x00 0x04
Name Access
0x01 0x03 0x02 0x01 0x04
Name Access
0x01 0x03 0x02 0x02 0x04
Name Access
0x01 0x03 0x03 0x20 0x04
UPSI-IP-1 series | UPSI- IP-2 series
Type Min.
R Int32
Type Min.
R Int32
Type Min.
R Int32
Type Min.
R Int16
Max Unit
0 +150 °C
Max Unit
0 +32768 mA
Max Unit
0 +32768 mV
Max Unit
0 32768 mV
