OPERATION PANEL

9
8
1
POWER ON / OFF Button
2
INTELLIGENT MODE Button, Indicator Light (White)
3
CLEAN ION SHOWER Button, Indicator Light (White)
Plasmacluster Ion SPOT Button,
4
Indicator Light (White)
5
HUMIDIFY ON / OFF Button, Indicator Light (White)
6
MODE Button, Indicator Light (White)

FRONT DISPLAY

8
Humidity / Temperature Monitor
Indicates the approximate humidity level or
temperature in the room. The humidity setting cannot
be adjusted.
Humidity 20% to 90% is displayed.
20%
or less
Temperature 0
1
-1 o C
or less
Wattage Monitor
Indicates wattage by current operation.
Timer Monitor
Indicates setting time or remaining time of ON/OFF
timer.
2
Plasmacluster Ion Light (Blue)
Humidify Light
Green
3
Off
Red(Flashing)
KC-G60_50_40EU_EN.indd 6
Press the button with "
10
7 6 5
7 6 5
90%
or more
o o
C to 50 C is displayed.
50 o
or more
Humidity ON
Humidity OFF
Unit needs water
" to start.
KC-G40EU
4 3
ON / OFF TIMER Button, Indicator Light (White)
7
<Press 3 sec.> FILTER RESET Button
DISPLAY SELECT Button
8
<Press 3 sec.> CHILD-LOCK Button
9
CHILD-LOCK Indicator Light (White)
10
FILTER RESET Indicator Light (Orange)
11
Light Sensor
9
4 3 2
Patrolling Light (Green / Orange / Red)
4
(Ref.E-9, E-10)
Odour Light (White)
5
Indicates the Odour Sensor detects odours.
Dust Light (White)
6
Indicates the Dust(sensitive) Sensor detects usual
dust.
C
PM2.5 Light (White)
Indicates the Dust(sensitive) Sensor detects
7
microscopic dust. (particulate matter less than 2.5
microns)
8
Motion Sensor
Cleanliness Monitor
Indicates the air purity of the room in 7 levels with
colour changes.
9
Blue
Clean
E-6
11
2 1
Front Louver
1
(KC-G60EU / KC-G50EU)
(KC-G60EU / KC-G50EU)
Red
Impure
