Sharp KC-G60Y Operation Manual

Air purifier with humidifying function
Hide thumbs

Advertisement

Quick Links

KC-G60Y
KC-G50Y
KC-G40Y
"Plasmacluster" and "Device of a cluster of
grapes" are trademarks of Sharp Corporation.
Tipe Berdiri
Free standing type
PEMBERSIH UDARA
dengan Fungsi Pelembaban
PETUNJUK PENGOPERASIAN
AIR PURIFIER
with Humidifying Function
OPERATION MANUAL
* The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm
which is measured around the center of a room with the
"high-density plasmacluster 7000" applicable floor area (at
1.2 m height above the floor) when the product is placed
close to a wall at the MED mode setting.
3
,

Advertisement

loading

  Related Manuals for Sharp KC-G60Y

  Summary of Contents for Sharp KC-G60Y

  • Page 1 Humidifying Function OPERATION MANUAL “Plasmacluster” and “Device of a cluster of grapes” are trademarks of Sharp Corporation. * The number in this technology mark indicates an approximate number of ions supplied into air of 1 cm which is measured around the center of a room with the Tipe Berdiri “high-density plasmacluster 7000”...
  • Page 2 FITUR Kombinasi Unik Teknologi Penyehatan MENYEGARKAN UDARA Udara Dengan menyemburkan ion-ion positif dan negatif Sistem Penyaringan Tiga Lapis + Plasmacluster + yang seimbang, penyehat udara Plasmacluster Pelembaban menyajikan proses alami. MENAHAN DEBU KELEMBABAN Pra-filter menahan debu yang lebih besar dari sekitar Mengendalikan kelembapan dengan merasakan 240 mikron partikel.
  • Page 3 ....Pra-Filter SPESIFIKASI Y-15 ..........Terima kasih atas kepercayaan anda membeli Air Purifier SHARP. Bacalah panduan ini secara seksama sebelum menggunakannya. Setelah itu, simpan panduan ini ke lokasi yangmudah dikenali untuk referensi. CATATAN • Pemurni udara dirancang untuk membuang debu yang terkandung di udara dan bau yang ditimbulkannya.
  • Page 4 PETUNJUK PENTING KESELAMATAN Selalu ikuti langkah-langkah pencegahan untuk • Hanya Pusat Service resmi SHARP yang keselamatan dasar bilamana menggunakan seharusnya menangani servis air purifier peralatan elektrik, termasuk berikut ini: ini. Hubungi Pusat Service terdekat bila dijumpai masalah, memerlukan pengaturan atau perbaikan.
  • Page 5 membuat unit langsung terkena uap. membersihkan Nampan Pelembap Udara. • Selalu operasikan unit pada posisi • Jangan lepaskan Pelampung. menghadap ke depan. Jika copot, baca Y-13. • Bila memindahkan unit, gunakan pegangan • Jangan gunakan deterjen untuk perawatan pada kedua sisi. Penutup dan Nampan Pelembap Udara.
  • Page 6 NAMA-NAMA BAGIAN DEPAN 20° 20° Pegangan (2 Lokasi) Sensor (Internal) Suhu / Kelembapan / Bau* (*KC-G60 / KC-G50) Celah Udara Keluar (Depan) Penahan Roda Pinggiran (Kanan & Kiri) Panel Pengoperasian Cara mengunci penahan roda pinggiran Kisi-Kisi Depan (Dapat disesuaikan) (Kanan & Kiri) Tampilan Depan Terkunci Terbuka...
  • Page 7 PANEL PENGOPERASIAN Tekan tombol dengan " " untuk memulai. KC-G40 Tombol MENYALA / MATI Tombol TIMER MENYALA / MATI, Lampu Indikator (Putih) <Tekan 3 detik> Tombol RESET FILTER Tombol MODE INTELIGEN, Lampu Indikator (Putih) Tombol ANTI DUST, Lampu Indikator (Putih) Tombol PILIH TAMPILAN <Tekan 3 detik>...
  • Page 8 PERSIAPAN Selalu pastikan Anda sudah melepaskan steker daya dari stop kontak di dinding. PEMASANGAN FILTER Buka Panel Belakang. Pasang Filter dengan urutan yang benar seperti yang ditunjukkan. Filter HEPA Tanda Panel Belakang Filter Penghilang Bau Lepaskan kantong plastik Pasang Panel Belakang. dari masing-masing filter.
  • Page 9 ION PLASMACLUSTER PENGATURAN PELEMBAPAN MODE SPOT MENGISI ULANG TANGKI AIR Gunakan mode ini saat Anda ingin menghilangkan bau yang melekat, kuman, dan zat-zat lain dari kain, sofa, dan tirai. Lepaskan Tangki Air. Sesuaikan Kisi-Kisi Depan secara manual. CATATAN Isi Tangki Air dengan •...
  • Page 10 TIMER MENYALA BAGAIMANA CARA MENGUBAH BERBAGAI Pilih lamanya waktu yang Anda inginkan. Unit otomatis Anda dapat mengubah fungsi dalam tabel "Tipe pengaturan" di halaman berikutnya. memulai setelah waktu yang dipilih terlewati. Matikan listrik pada unit. (saat unit MATI) lebih dari 3 detik Pilih "Nomor fungsi"...
  • Page 11 PENGATURAN Tipe pengaturan Fungsi Pengaturan Otomatis (default) Lampu secara otomatis MENYALA atau MATI tergantung pada kecerahan ruangan. Ruangan cerah: lampu MENYALA Ruangan gelap: lampu MATI Kontrol Cahaya Lebih gelap Anda dapat memilih kecerahan Tampilan Depan, Monitor Kebersihan, dan LED Celah Udara Keluar. Matikan ●...
  • Page 12 PERAWATAN DAN PEMELIHARAAN INDIKATOR FILTER TANGKI AIR Lampu Indikator filter akan menyala setelah kurang lebih 720 Bilas bagian jam. (30 hari × 24 jam =720 jam) dalam dengan air. RESET CATATAN Cara membersihkan kotoran membandel. lebih dari Bersihkan bagian 3 detik dalam Tangki Air dengan sepon lembut dan Tutup...
  • Page 13 NAMPAN FILTER DAN NAMPAN PELEMBAP UDARA BAGAIMANA CARA MELEPASKAN FILTER PELEMBAP DAN NAMPAN. BAGAIMANA CARA Abu-Abu Putih MEMASANG FILTER PELEMBAP DAN NAMPAN. Setelah perawatan, pasang kembali komponen dengan benar. Filter Pelembab Nampan Pelembab Udara Lepaskan Tutup Nampan Pelembab Udara. Bilas dengan air banyak. Tutup Nampan Bilas dengan air banyak.
  • Page 14 FILTER HEPA / FILTER PENGGANTIAN FILTER PENGHILANG BAU KAPAN HARUS MENGGANTI FILTER Hilangkan debu di Filter HEPA dan Filter Masa pakai filter beragam, tergantung pada lingkungan Penghilang Bau. ruangan, kondisi penggunaan, dan lokasi unit. Jika debu atau bau terus melekat, ganti filter. PERINGATAN Rentang masa pakai filter HEPA dan filter Penghilang Bau dan saran penggantian didasarkan pada pemurnian...
  • Page 15 PM2.5 lokal. TAMPILAN ERROR Jika error terus berlanjut, hubungi Pusat Servis Sharp. INDIKASI DIGITAL PENANGANAN Pastikan bahwa Filter Pelembab dan Nampan Pelembab sudah terpasang dengan benar, lalu NYALAKAN kembali daya.
  • Page 16 SPESIFIKASI Model KC-G60 KC-G50 KC-G40 Tegangan Listrik AC 220-240 V 50-60 Hz MAKSIMUM SEDANG RENDAH MAKSIMUM SEDANG RENDAH MAKSIMUM SEDANG RENDAH Penyetelan Kecepatan Kipas Kecepatan kipas (m /jam) BERSIHKAN Daya listrik (W) UDARA Level Kebisingan (dBA) Kecepatan kipas (m /jam) BERSIHKAN &...
  • Page 17 MEMO Y- 16...
  • Page 18 FEATURES A unique Combination of Air Treatment FRESHENS Technologies By emitting a balance of positive and negative ions, Triple Filtration System + Plasmacluster + Plasmacluster air treatment is a natural process. Humidification HUMIDIFIES TRAPS DUST Controls humidity by sensing temperature and Pre-filter traps dust larger than approx 240 micron humidity automatically...
  • Page 19: Table Of Contents

    E-14 ......Deodorizing Filter SPECIFICATIONS E-15 ........Pre-Filter Thank you for purchasing this SHARP Air Purifier. Please read this manual carefully before using the air purifier. After reading, keep the manual in a convenient location for future reference. NOTE •...
  • Page 20: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • Only a Sharp Authorized Service Center Always follow basic safety precautions when using electrical appliances, should service this air purifier. Contact the including the following: nearest Service Center for any problems, adjustments, or repairs. • Do not operate the unit in rooms where WARNING –...
  • Page 21: Installation Guidelines

    • Do not use the detergents for maintenance • Always operate the unit in an upright position. of the Humidifying Tray and Cover. If cause deformation, tarnishing, cracking • When moving the unit, use the handles on (water leakage). both sides. •...
  • Page 22: Part Names

    PART NAMES FRONT 20° 20° Handle (2 Locations) Sensor (Internal) Temperature / Humidity / Odor* (*KC-G60 / KC-G50) Air Outlet (Front) Caster Stopper (Right & Left) Operation Panel To Lock a caster stopper (Right & Left) Front Louver (Adjustable) Front Display Locked Unlocked Front...
  • Page 23: Operation Panel

    OPERATION PANEL Press the button with " " to start. KC-G40 POWER ON / OFF Button ON / OFF TIMER Button, Indicator Light (White) <Press 3 sec.> FILTER RESET Button INTELLIGENT MODE Button, Indicator Light (White) ANTI DUST Button, Indicator Light (White) DISPLAY SELECT Button <Press 3 sec.>...
  • Page 24: Preparation

    PREPARATION Always be sure to remove the power plug from the wall outlet. FILTER INSTALLATION Remove the Back Panel. Install the filters in the correct order as shown. HEPA Filter Back Panel Deodorizing Filter Remove the plastic bag Install the Back Panel. from the each filter.
  • Page 25: Plasmacluster Ion Spot Mode

    PLASMACLUSTER ION HUMIDIFICATION SETTING SPOT MODE REFILLING THE WATER TANK Use this mode when you want to remove adhering odor, germs, and other substances from cloths, sofas and curtains. Remove the Water Tank. Adjust Front Louver manually. NOTE Fill the Water Tank •...
  • Page 26: On Timer

    ON TIMER HOW TO CHANGE VARIOUS Select the length of time you want. The unit automatically You can change the functions in the "Type of setting" table on the next page. starts once the selected time is passes. Turn the unit power OFF. (with the unit OFF) more 3 sec.
  • Page 27 SETTINGS Type of setting Function Setting Auto (default) Light automatically switches ON or OFF based on room brightness. Room is bright: light is ON Room is dark: light is OFF Light Control Darker You can select the brightness of the Front Display, Cleanliness Monitor Turn off and Air Outlet LED.
  • Page 28: Care And Maintenance

    CARE AND MAINTENANCE FILTER INDICATOR WATER TANK The filter reset Indicator light will turn on after approximately Rinse the inside 720 hours operating. (30 days × 24 hours =720 hours) with a water. RESET NOTE How to clean hard to remove dirt. more Clean the inside of 3 sec.
  • Page 29: Humidifying Filter And Tray

    HUMIDIFYING FILTER AND TRAY HOW TO REMOVE THE HUMIDIFYING FILTER AND TRAY. HOW TO ATTACH THE Gray White HUMIDIFYING FILTER AND TRAY. After maintenance, correctly reattach the parts. Humidifying Filter Humidifying Tray Remove the Humidifying Tray Cover. Rinse with plenty of water. Tray Cover Rinse with plenty of water.
  • Page 30: Hepa Filter / Deodorizing Filter

    HEPA FILTER / FILTER REPLACEMENT DEODORIZING FILTER LIFE OF FILTERS Remove the dust on the HEPA Filter and Filter life varies depending on the room environment, Deodorizing Filter. usage conditions, and location of the unit. Lifespan of HEPA filter and Deodorizing filter and CAUTION replacement suggestions are based on purifying a room in which 5 cigarettes are smoked per day and...
  • Page 31: Troubleshooting

    PM2.5 data. ERROR DISPLAY If error occurs repeatedly, contact the Sharp Service Center. DIGITAL INDICATION REMEDY Make sure that the Humidifying Filter and Humidifying Tray are properly installed, and then turn the power to ON again.
  • Page 32: Specifications

    When the unit’s power plug is inserted in a wall outlet it consumes about 0.6 watts of standby power in order to operate electrical circuits. To conserve energy, unplug the power cord when the unit is not in use. PT. SHARP TRADING INDONESIA Kawasan Industri KIIC, Jl. Harapan Raya Lot LL 1&2, Gedung NO. 01 Desa Sirnabaya, kec.
