PART NAMES

FRONT
1
2
3
4
To Lock a caster stopper (Right & Left)
Locked
Unlocked
BACK
1
2
3
4
5
1
Water Tank
2
Tank Cap
3
Humidifying Filter
4
Float
5
Humidifying Tray
Dust(sensitive) Sensor /
6
Sensor Filter
KC-G60_50_40EU_EN.indd
5
5
6
7
8
9
Front
7 8
6
(Plug shape varies by country.)
7
Back Louver
8
Air Outlet (Back)
9
Air Outlet LED(White)
10
HEPA Filter
11
Deodorizing Filter
12
Back Panel (Pre-Filter)
13
Air Inlet
14
Power Cord / Plug
20°
20°
1
Handle (2 Locations)
Sensor (Internal)
2
Temperature / Humidity / Odour*
(*KC-G60EU / KC-G50EU)
3
Air Outlet (Front)
4
Caster Stopper (Right & Left)
5
Operation Panel
6
Front Louver (Adjustable)
7
Front Display
8
Unit
9
Caster (4 Locations)
9
10
11
12
13
14
E-5
Detection range
Light Sensor
Do not install the unit in the
following places.
The Light Sensor may not sense
correctly.
In shadow
Directly under
a light fixture.
Motion Sensor
(KC-G60EU / KC-G50EU)
Sensory range is the area shown
below.
Front
1.6m
30°
30°
2m
Right and Left
2.3m
30°
30°
2m
