Configuring The Acl; Range Of Mus - Symbol Spectrum24 AP-4131 Product Reference Manual

2.8.1

Configuring the ACL

The ACL supports adding MU entries by individual MAC address or by a
range of MAC addresses.
1. Select the Set Access Control List option from the Main Menu to display:
2. Use the UP/DOWN-ARROW keys to toggle between
2.8.2

Range of MUs

To select a range of MAC addresses:
1. Type in the minimum MAC address as the top value:
2. Press ENTER to accept the value; use the DOWN-ARROW key to select
3. Type in the maximum MAC address in the bottom value:
4. Press ENTER to accept the value; use the DOWN-ARROW key to
5. Press ENTER. The UI displays:
6. Verify values reflect the network environment. Change them as needed.
AP-4131 Access Point Product Reference Guide
.
the maximum value.
select OK.
Configuring the AP
and
113
