- Page 1 Installation Instructions Pivot Tap Range Models covered: PIV 3HBAS C, PIV 3HBF C, PIV 5HBSM C Please keep this booklet for future reference. Installer, when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents Thank you for choosing Bristan, the UK’s leading taps and showers expert. We have designed this product with your enjoyment in mind. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to contact us. -
Page 3: Important Safety Information
Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. •... -
Page 4: General Information
General Information This product has been tested to the Water Regulations Advisory Scheme (WRAS) and satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and current bylaws. For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory. Designed to comply with BS EN 200 for combination taps to be used within systems designed to BS 8558. -
Page 5: Dimensions
Dimensions 3 Hole Basin Mixer 3 Hole Bath Filler Dimensions are approximate and in millimetres. Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. -
Page 6: Dimensions
Dimensions Cont. 5 Hole Bath Shower Mixer Dimensions are approximate and in millimetres. Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. -
Page 7: Installation Requirements
Installation Requirements Flexible Connecting Pipes Care must be taken when connecting the flexible connection pipes to the household pipework to ensure they do not bend sharply and kink or twist. See below for recommended ways to fit the flexible connecting pipes. Slight 90°... -
Page 8: Installation
Installation 3 Hole Basin Mixer & Bath Filler 1. With the backnut, metal and rubber washer fitted to the side body threaded tail, feed the side body through the hole in the basin/ bath from underneath and secure in position by screwing the plinth onto the side body valves, ensuring that the washers are fitted between the plinths and the basin/ bath to create a water tight... - Page 9 Installation Cont. 3 Hole Basin Mixer & Bath Filler Cont. 7. Attach the T- joint assembly and connect to the side bodies (hot on the left, cold on the right when viewed from the front), by using the flexi tails supplied. 8.
-
Page 10: Hole Bath Shower Mixer
Installation Cont. 5 Hole Bath Shower Mixer 1. With the backnut, metal and rubber washer fitted to the side body threaded tail, feed the side body through the hole in the bath from underneath and secure in position by screwing the plinth onto the side body valves, ensuring that the washers are fitted between the plinths and the bath to create a water tight seal. - Page 11 Installation Cont. 5 Hole Bath Shower Mixer Cont. 7. Connect the side bodies to the diverter using the flexi tails supplied. 8. Connect the spout to the diverter using the flexi tail supplied. 9. Fit the shower head holder to the bath. Remove the backnut and the washers and feed the threaded tail through the hole in the bath.
-
Page 12: Maintenance
Wash the valve with clean running water and make sure that any debris has been removed. If necessary replace the valve using parts supplied by Bristan only. Lightly grease the seal (only use silicone grease), replace the valve, plinth, valve shroud and the handle. -
Page 13: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or low Partially closed isolation valve. Open isolation valve. flow rate Instantaneous water heater Increase water flow rate or cycles on and off as flow rate or pressure through system to pressure is too low. meet required minimum working pressure of tap. -
Page 14: Guarantee
Guarantee At Bristan, we want to make things as • Repair under this guarantee does not easy as possible for our customers. That’s extend the original expiry date. The why we design products that are easy to guarantee on any replacement parts or fit and use, and that are quality tested to product ends at the original expiry date. -
Page 15: Guarantee
‘phone or with a spare part, then we’ll guarantee period, contact Bristan Care send out one of our Bristan Care Customer Service on 0844 701 6273 with engineers to take a look. Bristan Care... - Page 16 PIV BOOK 3 Part Numbersa: Issue: D1 Useful contact details: Customer Service: 0844 7016273 Bristan Group Ltd. Customer Service Email: Birch Coppice Business Park Customercare@bristan.com Dordon Tamworth Customer Service Fax: Staffordshire 0844 7016275 B78 1SG Reception: Web: www.bristan.com 0844 7016274 Email: enquire@bristan.com...
