Bristan N2 SHCDIV C Installation Instructions And User Manual

Bristan N2 SHCDIV C Installation Instructions And User Manual

Thermostatic recessed dual control shower valve with integral diverter
Hide thumbs Also See for N2 SHCDIV C:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Instructions
and User Guide
Thermostatic Recessed
Dual Control Shower
Valve with Integral
Diverter
Models covered: N2 SHCDIV C,
N2 SHCDIV G, AR3 SHCDIV C,
PM2 SHCDIV C, RS SHCDIV C,
DSC SHCDIV C
Please keep this booklet for future
reference.
Installer, when you have read these
instructions please ensure you leave
them with the user.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N2 SHCDIV C and is the answer not in the manual?

Questions and answers

Related Manuals for Bristan N2 SHCDIV C

Summary of Contents for Bristan N2 SHCDIV C

  • Page 1 Installation Instructions and User Guide Thermostatic Recessed Dual Control Shower Valve with Integral Diverter Models covered: N2 SHCDIV C, N2 SHCDIV G, AR3 SHCDIV C, PM2 SHCDIV C, RS SHCDIV C, DSC SHCDIV C Please keep this booklet for future reference.

  • Page 2: Table Of Contents

    Contents Thank you for choosing Bristan, the UK’s leading showers and taps expert. We have designed this product with your enjoyment in mind. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0844 701 6273.

  • Page 3: Important Safety Information

    Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. • If you are in any doubt about your ability to install this product safely you must employ the services of an experienced qualified plumber.

  • Page 4: General Information

    General Information This product has been tested to the Water Regulations Advisory Scheme (WRAS) and satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and current bylaws. For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory. BS7600 recommends the temperature of stored water should never exceed 65ºC. A stored water temperature of 60ºC is considered sufficient to meet all normal requirements and will minimise the build up of lime scale in hard water areas.

  • Page 5: Product Features

    Turn the handle clockwise for a cooler temperature. Turn the handle anti-clockwise for a hotter temperature. Note: The N2 SHCDIV C/G & RS SHCDIV C can either be installed por- PM2 SHCDIV C shown trait or landscape. Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.

  • Page 6: Specifications

    Note: When using a pumped system we recommend that an essex flange is used. Important: Minimum wall cavity depth: 35mm Min - Max Concealing plate thickness: 45-75mm For full dimensional drawings please visit www.bristan.com. Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.

  • Page 7: Pack Contents

    Pack Contents - N2 SHCDIV C/G 1. Concealing plate x1 2. Valve body x1 3. Handles x2 4. Shrouds x2 5. Shroud extention screws x1 6. Valve body fixings x2/2 7. Inserts x2 8. Flow regulators x2 9. Filter washers x2 10.
  • Page 8 Pack Contents - AR3 SHCDIV C 1. Concealing plate x1 2. Valve body x1 3. Handles x2 4. Valve body fixings x2/2 5. Inserts x2 6. Flow regulators x2 7. Filter washers x2 8. Wall outlet x1 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.
  • Page 9 Pack Contents - PM2 SHCDIV C 1. Concealing plate x2 2. Valve body x1 3. Handles x2 4. Spline adaptors x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.
  • Page 10 Pack Contents -RS SHCDIV C 1. Concealing plate x1 2. Valve body x1 3. Handle x1 4. Lever x1 5. Shrouds x2 6. Shroud extention screws x2 7. Valve body fixings x2/2 8. Inserts x2 9. Flow regulators x2 10. Filter washers x2 11.
  • Page 11 Pack Contents - DSC SHCDIV C 1. Concealing plate x2 2. Valve body x1 3. Handles x2 4. Spline adaptors x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.

  • Page 12: Prior To Installation

    Prior to Installation Flow Regulators This shower valve is supplied with a 5 and 7 litre per minute flow regulator loose in the box which must be fitted if the shower Filter valve is installed in conjunction with an Washer instantaneous water heater / combination boiler.

  • Page 13: Installation

    Installation - Shower Valve This shower valve is designed for installations where a recessed valve is already installed in the wall cavity and is to be replaced or for new installations. Wall plugs Before Installation Flush through the pipework to ensure removal of any debris.
  • Page 14 Installation - Shower Valve 4. Fit concealing plate Note: The concealing plate can be used as a template by drawing around the plate and measuring in by 10mm to give sufficient clearance. See page 18 for concealing plate adjustment. Run a bead of waterproof silicon sealant around the inner edge of the concealing plate.

  • Page 15: Wall Outlet

    Installation - Wall Outlet Fitting the Wall Outlet There are two methods of fixing the wall Backnut outlet depending on the type of wall: a: With rear access once wall finished Fit the rubber washer to the back of the Rubber wall outlet, place the assembly through a seal...

  • Page 16: Operating The Shower

    Operating the Shower 1. Two outlet diverter This outlet allows the user to divert the flow of water from one product to another. Turn the handle one way or the other to turn the flow of water on to your chosen product.

  • Page 17: Maintenance

    • Turning off the isolation valves to the shower valve. 4. Grease the seals with a silicon grease 1. Remove the temperature handle and supplied by Bristan (part number: SP-495- plastic stop. 0002) and carefully refit. Important: Take note of the position 5.

  • Page 18: Adjusting The Temperature

    Adjusting the Temperature Adjusting the Temperature temperature of the water with a The shower valve has been factory set to thermometer. If the temperature is not 42ºC with equal (balanced) hot and cold correct, re-calibrate the shower valve: water supply pressures, with the hot water 1.

  • Page 19: Troubleshooting

    Troubleshooting Symptom Cause Remedy No flow or low Check showerhead, hose and Clean as necessary, refer to flow rate and filters for any blockage. Maintenance section (page 17). / or varying Partially closed stop or service Open stop or service valve. temperatures.
  • Page 20 Troubleshooting Symptom Cause Remedy Maximum water Maximum water temperature Reset maximum water temperature too set incorrectly. temperature. Refer to ‘Maximum hot or cold. Temperature setting’ in Maintenance section (page 17) and ‘Adjusting the Temperature’ (page 18) Outlet water Inlet filter is partially blocked. Check inlet filters for any temperature too blockages and clean as...

  • Page 21: Notes

    Notes please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisers.

  • Page 22: Guarantee

    Guarantee At Bristan, we want to make things as • Repair under this guarantee does not easy as possible for our customers. That’s extend the original expiry date. The why we design products that are easy to guarantee on any replacement parts or fit and use, and that are quality tested to product ends at the original expiry date.
  • Page 23 ‘phone or with a spare part, then we’ll guarantee period, contact Bristan Care send out one of our Bristan Care Customer Service on 0844 701 6273 with engineers to take a look. Bristan Care...
  • Page 24 Part Number: FI: SHCDIV FA Issue: D6 Useful contact details: Customer Service: 0330 026 6273 Bristan Group Ltd, Customer Service Email: Birch Coppice Business Park Customercare@bristan.com Dordon Tamworth Staffordshire B78 1SG Join us on... Web: www.bristan.com Email: enquire@bristan.com A Masco Company...
  • Page 25 Prior to Installation Spare Parts All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.

  • Page 26: Installation

    Typical Installation Important * - not supplied ~ - check pack contents The images shown are for if supplied Locking Nut Stud illustrative purposes only. Partition* The product you have purchased 1/2” BSP may look different to those pictured Female in this booklet but will follow the Connector* same installation steps.
  • Page 27 (not supplied) and to your wall arm. Push the shroud into position. General Cleaning Bristan products are made from Screw your premium materials, with hand polished, chosen shower electroplated, PVD or EPD finishes. rose onto the shower arm by HAND ONLY.

  • Page 28: Our Guarantee

    A Masco Company Our Guarantee At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind.

  • Page 29: Operation

    Prior to Installation Spare Parts All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
  • Page 30 Luxembourg Our Guarantee At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind. To start your free guarantee simply scan the QR code and register your product.
  • Page 31 If in doubt, contact a registered plumber or your Local Water Authority or the Secretary of the Institute of Plumbing, address as follows;- At Bristan, we want to make things as easy as possible for our customers. To replace any spare parts That’s why we offer solid guarantees on all our products, effective from the date of purchase,...

This manual is also suitable for:

N2 shcdiv gAr3 shcdiv cPm2 shcdiv cRs shcdiv cDsc shcdiv c
