Bristan PM2 SHCDIV C D9 Installation Instructions & User Manual

Specifications
Cold Water Supply
Dynamic Water Pressure
Min: 0.2 bar Max: 5.0 bar
3.0 3.0
2.0 2.0
4.0 4.0
1.0 1.0
0. 5.0 0. 5.0
Min: 5°C Max: 25°C
Pressure Pressure
BAR BAR
IMPORTANT
Maximum Static Pressure: 10.0 bar
Tools You'll Need
23
mm
Socket Cross Head Adjustable
Drill
Spanner Screwdriver Spanner
Prior to Installation
All products manufactured and supplied by Bristan are safe to use
provided that they are installed, operated and receive regular
maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the
requirements of The Water Supply (Water Fittings) Regulations
(Northern Ireland) 2009 and The Water Supply (Water Fittings)
(Scotland) Byelaws 2014. For full Installation Requirements & Notes (IRN)
please visit wras.co.uk/directory.
Isolation valves must be fitted to the inlet water supplies to ensure ease
of future maintenance.
Before installing this product the water supply must be thoroughly
flushed in order to remove any swarf, solder etc. Full access must be
made available for future maintenance/servicing purposes.
Before drilling into walls, check that there are no hidden electrical
wires, cables or water supply pipes. This can be checked with the
aid of an electronic detector.
If power tools are used do not forget to:
- Wear eye protection
- Unplug equipment after use
This product must not be modified in any way
as this will invalidate the guarantee.
If in doubt, contact a registered plumber, your Local Water
Authority or the Secretary of the Institute of Plumbing,
address as follows:-
The Institute of Plumbing,
64 Station Lane,
Hornchurch,
Essex,
RM12 6NB, Tel: 01708 472791
Installation Instructions
& User Guide
Please leave these instructions
with the end user
Product Code: PM2 SHCDIV C (D9)
Inlet Water Temperature
Inlet Dimensions
Hot Water Supply
80°C
25°C
5°C
65°C Recommended
The inlet hot water must
be at least 10°C above the
required blend temperature.
2.5
mm
Pipe & Wire
Pipe Cutter Hexagonal Keys
Silicon Sealant
Detector
Cavity Dimensions (mm)
Minimum
Fitting Depth: 50mm
Maximum
Fitting Depth: 75mm
Concealing Plate
Adjustment Range: 25mm
Pack Contents
x1
x1
x2
x1
x2
Valve Configuration
1
Yellow Flow
Limiter (Hot)
Installation
150
1
Centres
Install suitable
Inlet Connections
batons (if required)
into the cavity. Take the
15mm finished wall surface into
consideration when fitting
Compression
the valve into the cavity.
Mark the position of
the valve; drill and
plug holes to suit.
3
Spirit Level
Hot
Cold
Connect the inlet
pipes ensuring the
olives are fitted.
25 50 6
x2
x1
x2
2
Increase
Temperature
x2
Temperature
Green Flow
Limiter (Cold)
Remove the inlet elbows and filters.
Remove the plastic inserts from the valve
inlets and insert the flow regulators.
Replace the elbows, ensuring the
filters are fitted.
2
Cavity Space
75mm
50mm
Baton
Ensuring the valve is straight, secure
the valve using the screws supplied
(solid walls only) or a suitable alternative.
4
Plumb your
chosen
outlets into
the valve.
Turn on the water supply
and check the valve for
any leaks.
Temperature Adjustment
1
Fit the
handles.
2.5
mm
3
Turn the spindle
to increase or
decrease the
temperature.
Check the
Fit the temperature
temperature and
handle back
adjust until you
in the maximum
Decrease achieve the
hot position.
desired result.
2
Screw the shrouds
onto the valve.
5
Draw around
the concealing
plate as a template,
measuring in by
10mm to give
clearance. Finish the
wall surface. Using a
silicon sealant, push
on the concealing
plate and hold
firmly until set.
Turn the handle to
the maximum
2.5
temperature setting,
mm
then remove it.
2.5
mm
