Trigger Value: sets the value ("0", "1" or "0/1", being the latter the default
option) that will trigger, when received through "[ML] Trigger", the master
action (the general switch-off or the courtesy switch-on).
General Switch-Off.
 Delay: defines a certain delay (once the trigger has been received) before
 Binary Value: if checked, object "[ML] General Switch-off: Binary
 Scaling: if checked, object "[ML] General Switch-off: Scaling" will be
 Scene: if checked, object "[ML] General Switch-off: Scene" will be
 HVAC: if checked, object "[ML] General Switch-off: HVAC mode" will be
Note: the above options are not mutually exclusive; it is possible to send
values of different nature together.
Courtesy Switch-On:
The parameters available here are entirely analogous to those already
mentioned for General Switch-Off. However, in this case the names of the
objects start with "[ML] Courtesy Switch-On (...)". On the other hand,
sending scene save orders is not possible for the courtesy switch-on (only
orders to play scenes are allowed).
Note: object "[ML] Courtesy Switch-On: Binary Object" sends the value "1"
(when the courtesy switch-on takes place), in contrast to object "[ML]
http://www.zennio.com
the execution of the general switch-off. The allowed range is 0 to 255
seconds.
Object" will be enabled, which will send one "0" whenever the general
switch-off takes off.
enabled, which will send a percentage value (configurable in "Value")
whenever the general switch-off takes off.
enabled, which will send a scene run / save order (configurable in "Action"
and "Scene Number") whenever the general switch-off takes off
enabled, which will send an HVAC thermostat mode value (configurable in
"Value", being the options "Auto", "Comfort", "Standby", "Economy" and
"Building Protection") whenever the general switch-off takes off
