Page 1: Installation Guide
PoE Driven Power Supply with Lithium Battery Backup Installation Guide Tango1B More than just power. Rev. TANGO-071119... -
Page 2: Specifications
Tango 8-pin connector allows for stacking with compatible Altronix sub-assemblies such as ACMS8 and PDS8, saving valuable enclosure space. Tango1B is designed to support a single 12V LiFePO 4 (Lithium Iron Phosphate) battery for high storage and charge/discharge cycle life reliability. -
Page 3: Terminal Identification
24VDC output (Fig. 1e, pg. 3). + BAT – Lithium Iron Phosphate battery backup (Fig. 1f, pg. 3). 8-Pin Connector (Fig. 1g, pg. 3) Facilitates electrical connection to PDS8(CB) or ACMS8(CB). Tango1B - PoE Driven Power Supply with Lithium Battery Backup - 3 -... - Page 4 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IITango1B J14S - 4 -...
